DCA-800SSK (STD) — OPERATION AND PARTS MANUAL — REV. #4 (06/03/10) — PAGE 75
DCA-800SSK — GENERATOR ASSY.
GENERATOR ASSY.
NO PART NO PART NAME QTY. REMARKS
4 C5153000002 END BRACKET 1
5 C4137000003 FIELD ASSY., EXCITER 1
6 0012110075 HEX. HEAD BOLT 6
6 0042610000 LOCK WASHER 6
6 0041210000 PLAIN WASHER 6
7 0845044904 GROMMET 1
8 0016316045 HEX. HEAD BOLT 8
8 0040016000 LOCK WASHER 8
8 0041216000 PLAIN WASHER 8
9 C5153300003 COVER, BEARING 1
10 C5153300104 GASKET, BEARING 1
11 0016308095 HEX. HEAD BOLT 3
11 0040008000 LOCK WASHER 3
11 0041208000 PLAIN WASHER 3
12 0010110016 HEX. HEAD BOLT 1
13 0803000104 PACKING 1
14 8461335004 BRACKET, COVER 1
15 C5131300103 COVER, STATOR 1
16 0017106012 HEX. HEAD BOLT 4
17 0017106050 HEX. HEAD BOLT 2
18 8461333003 COVER, EXCITER 1
19 0017106012 HEX. HEAD BOLT 2
20 0012112040 HEX. HEAD BOLT 16
20 0042512000 LOCK WASHER 16
21 C5131300003 COVER, FAN 1
22 0017106050 HEX. HEAD BOLT 1
23 0605000012 RUBBER SUSPENSION 4
24 0030020000 HEX. NUT 8
24 0040020000 LOCK WASHER 8
