Section 7: Features and Benefits
RC5014 (540 RPM) and RCM5014 (1000 RPM) Rotary Cutters 330-117M 2/02/08
Land Pride
Table of Contents
Hinged wing section Allow cutter to follow terrain. Ideal for rough ground where hillsides, ditches and hollows can
cause uneven cutting.
1” Solid hinge rods Larger diameter hinge rod gives greater strength to the cutter from front to rear, and in the
hinge area itself.
Wing hydraulics 3 1/2” x 12” Cylinder to handle the large wing deck.
Wing transport locks Safety feature. Holds wing section up in case of hydraulic pressure loss.
8’ - 9” Transport width Transport width is safe and legal in most communities.
Enclosed front to rear dual
leveling rods
Dual leveling rods enable the cutter to pull equally on the rear axle during travel over rough
terrain. Many competitors only use one leveling rod.
5-Bolt hubs 5-Bolt hubs makes the wheel assembly more durable and longer lasting.
Drain holes in wheel rims Allows water to drain from wheels mounted on the folded-up wing.
Helps prevent paint deterioration and rusting to the wheel rims.
5” Square rear axle tubing Heavy axle to handle harsh conditions.
Spring-cushioned center-axle Protects unit from bumps and ground shock.
Replaceable wheel spindles Wheel spindles can be replaced when damaged without replacing the entire axle. Simply
remove two bolts to replace damaged spindle.
Features and Benefits Of Optional Equipment
5 or 6 Wheel option Outer wing wheel can be single (5-wheel option) or dual (6-wheel option).
Dual wheels on the outer wing is ideal when mowing in areas where the wing needs to flex
up hill. The outer wheel rides farther up the embankment and keeps the deck from gouging.
Also, the extra wheel on the outer wing deck provides better load distribution.
Wheel options Laminated tires: Eliminates flats.
Airplane tires without foam filling: Give better cushion while transporting.
Airplane tires with foam filling: Give better cushion while transporting and can’t go flat.
15" Wheel rims: Can mount your own tires.
Deck rings (optional) 1/2" x 3" full welded deck ring keeps blades from damaging the deck.
Front & rear shielding Choice allows customer to fit his needs.
Front Shielding: Rubber guard, single chain or double chain.
Rear Shielding: Rubber guard, single chain or double chain.
RC5014 and RCM5014
Features Benefits
