Specications
• Mounting: Hinged to tilt up for access to battery
and other components. Adjustable fore and aft.
• Armrests: Standard–padded ip-up armrests.
• Seat Safety Switch: Incorporated into the Safety
Interlock System.
Hydrostatic Ground Drive System
• Hydrostatic Pumps:
– 42 inch unit: Two Hydro Gear ZT2100
Integrated drive systems.
– 50 inch E-Series unit: Two Hydro Gear
ZT2200 Integrated drive systems.
– 50 inch S-Series unit: Two Hydro Gear
ZT2800 Integrated drive systems.
• Hydraulic Oil Type: Exmark Premium Hydro Oil.
• Speeds:
– 0-7.0 mph (11.3 km/hr) forward.
– 0-5.0 mph (8.0 km/hr) reverse.
• Drive wheel releases, located on left and right
sides of engine deck, allow machine to be moved
when the engine is not running and brake is off.
Tires and Wheels
Drive
Pneumatic (Air-Filled)
Deck Size
42 50 E-Series 50 S-Series
Quantity
2 2 2
Tread
Hoosier
Premium
Hoosier
Premium
Carlisle Turf
Master
Size 18 x 7.50-8 18 x 9.50-8 20 x 8-10
Ply Rating
2
4 4
Pressure
13 psi
(90 kPa)
13 psi
(90 kPa)
13 psi
(90 kPa)
Front Caster
Pneumatic (Air-Filled)
Deck Size
42 50
Quantity
2 2
Tread
Smooth
Ribbed
Size
410/350 x 4
13 x 5-6
Ply Rating
2 2
Pressure
20 psi
(138 kPa)
13 psi
(90 kPa)
Cutting Deck
• Cutting Width:
– 42 inch Deck: 42 inches (107 cm)
– 50 inch Deck: 50 inches (127 cm)
• Discharge: Side
• Blade Size:
– 42 inch Deck: 21.60 inches (54.9 cm)–Qty: 2
– 50 inch Deck: 17.50 inches (44.5 cm)–Qty: 3
• Blade Spindles: Solid steel spindles with no
maintenance bearings.
• Deck Drive: Electric clutch mounted on vertical
engine shaft. Blades are driven by one belt
(w/self-tensioning idler) direct from the engine.
• Deck: Full oating deck is attached to out-front
support frame. Maximum turf protection is
provided with anti-scalp rollers.
Deck design allows for bagging, mulching or side
discharge.
• Deck Depth:
– 42 inch Deck: 4.0 inches (10.2 cm)
– 50 inch Deck: 4.0 inches (10.2 cm)
• Cutting Height Adjustment: A hand deck lift lever
with foot assist is used to adjust the cutting height
from 1 1/2 inch (3.8 cm) to 4 1/2 inches (11.4
cm) in 1/2 inch (1.3 cm) increments.
• Mulching Kit: Optional.
Dimensions
Overall Width:
42 inch Deck 50 inch Deck
Without Deck 39.0 inches
(99 cm)
46.3 inches
(118 cm)
Deector Up 45.3 inches
(115 cm)
54.6 inches
(139 cm)
Deector Down 53.8 inches
(137 cm)
63.0 inches
(160 cm)
Overall Length:
42 inch Deck 50 inch Deck
71.8 inches (182 cm) 72.9 inches (185 cm)
