Aquatic Fitness System
2005 Owner’s Manual
37
Term (Cont.) Definition
Heater An 11kw 230v thermostatically controlled electric heater
equipped with a high-limit temperature safety shut-off switch.
If the high-limit safety switch trips, contact your authorized
Aquatic Fitness System Dealer. See the
Troubleshooting
Guide for more information.
Jets Return the water into the Aquatic Fitness System from the
equipment. The HydroTherapy Jets produce a turbulent flow
of water mixed with air to provide a concentrated body
massage. The Swim Jets produce a high volume flow to
provide a rapid current for swimming.
Light Illuminates the Aquatic Fitness System vessel.
Load Sharing When the circuit breaker size is smaller than the total power
needed to operate both the heater and the jet pump at the
same time, load sharing automatically turns off the heater
when a jet pump is turned onto high speed.
Lock-Ring Mechanism that affixes filter cover to filter housing. To
remove cover, turn lock-ring counter-clockwise until it
disengages with filter housing. When replacing the filter cover,
turn lock-wring clockwise to firmly secure the cover.
Ozone Generator A specialized ultraviolet light that changes oxygen into ozone
for use in the water sanitation process.
Pressure Switch Safety device that sends a signal to the electronic control
system that there is adequate water flow to turn the heater
on.
Primary Pump Produces water flow through the heater, filter, sanitation
system and the main jets in the Aquatic Fitness System. The
primary pump will operate automatically during filtration and
heat cycles. This pump can also be operated manually by
depressing the “jets” button on the Top Side Control which will
allow you to choose between two speeds
• Low speed for efficient water circulation during
heating and filtration modes, and for gentle jet
resistance or massage action.
• High speed for maximum jet action.
Pump Union A removable fitting that connects the pump to the Aquatic
Fitness System’s plumbing.
Selector Valve Located on the top edge of the Aquatic Fitness System or
spa, it diverts jet power from one area of the Aquatic Fitness
System or spa to another.
Serial Number Please use the serial number in communication with your
dealer.
Servicing Filter Element To clean or replace the filter element, shut off power to the
Aquatic Fitness System, loosen the lock-ring, remove the filter
cover and pull the filter element from the filter housing.
Depending upon use, you may simply rinse the filter element
with a garden hose, or you may be required to soak the
element in Filter Cleaner Solution. Replace any worn or
damaged filter elements. It is always good practice to have a
spare filter element, so that you can perform cleaning at your
convenience.
