GENERAL DIMENSIONS - P3DHX12F08001
Cabinet Plenum Openings Flue
Return Air
Width
(A)
Depth
(B)
Height
(C)
Supply Air
(D x E)
Top
(K x L)
Side
(F x G)
Dia.
(H)
Height
(J)
Filter
Shipping
Weight
22-¼ 22-¼
1
54-¾ 19 x 19 18 x 18 18 x 18 5 28-¼ 20 x 20 x 1 263 lb.
1
Add 8-½ inches to allow for burner, (30-¾ inches total).
Add 8-¾ inches to allow for add-on vestibule cabinet, (31 inches total). All dimensions in inches.
