Scag Power Equipment STT61V-27KA Lawn Mower User Manual



80
R
Section 8
ELECTRICAL SYSTEM - 29DFI KAWASAKI
Ref.
No.
Part No. Description
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
481755
48298
483366
462069
48017-04
48017-03
461916
48798
483162
48788
04031-01
04020-01
481183
451879
04030-02
04001-01
04110-01
481662
04010-01
481638
04001-44
48029-06
04020-02
48029-11
48030-09
48136-05
48030-11
481670
483626
04031-03
04002-12
483029
481945-01
483642
481182
483629
483571
482588
483643
483641
Ammeter
Fuse, 20 AMP
Key, Ignition
Key Assembly w/Fob
Nut, Hex 5/8-32
Lockwasher, 5/8” Internal
Instrument Panel, Top w/Decals
Key Switch
Switch, PTO
Relay
Lockwasher, #10 External Tooth
Nut, Hex #10-32
Water Temp. Gauge (STT - KA Only)
Base, Instrument Panel
Lockwasher, 1/4”
Bolt, Hex Head 1/4-20 x 3/4”
U-Nut, 1/4-20
Throttle Controls
Screw, Phillips Washer Head #10-32 x 1/2”
Switch, Interlock-Seat
Bolt, Hex Head 1/4-20 x 1/2”
Cable, Battery - Red
Nut, Hex 1/4-20
Cable, Battery - Black
Clamp, Cable 1/2” ID.
Clamp, Cable 3/4” ID.
Clamp, Cable
Sending Unit, Water Temp.
Wire Harness, STT Liquid-Cooled Digital Fuel Injection (DFI)
Lockwasher, 5/16” External Tooth
Bolt, Hex Head M8-1.25 x 20mm
Electronic Module
Heatshield, Flexible
Double Fuse Assembly, Sealed (Incl. items 2, 42, 43, 44)
Indicator Light, Check Engine
Fuse Holder
Cover, Sealed Double
Clip, Wire
Cover, Sealed Single
Single Fuse Assembly, Sealed (Incl. items 2, 35, 37, 38)
