Scag Power Equipment STT61V-27KA Lawn Mower User Manual



68
R
Section 8
FUEL AND HYDRAULIC SYSTEM
Ref.
No.
Part No. Description
Ref.
No.
Part No. Description
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
04110-01
48136-13
04001-03
48811
48136-07
481301-03
482266-01
48471-02
482606
**
**
483617
481308
481753
48059-01
483617
481602
48309
04001-09
04019-03
48758
482483
04021-08
481164
481507
48603-02
461451
482572
482571
48136-13
48811
04010-10
48571-02
461751
48136-05
48350-02
48350-05
48938-02
423701
04019-03
04003-02
482574
482573
423513
U-Nut 1/4-20
Hose Clamp, 0.69” Dia.
Bolt, Hex Head 1/4-20 x 2.0”
Hose, 3/8” ID Pushlock - (order by inch)
Clamp, Hose 1/2”
Elbow, 90 Degree - 1/4” NPT x 3/8” Hose
Elbow, 90 Degree - 9/16” O-Ring x 3/8”
Hose
Oil Filter Base
Hose Assembly, 1/2” ID (Tank to Filter
Base)
Fuel Hose to Carb.
Fuel Filter
Fuel Hose, 1/4” ID. Non-Perm. (order by
inch)
Valve, Shutoff Kawasaki
Valve, Shutoff Kohler
Clamp, Fuel Hose
Fuel Hose, 1/4” ID. Non-Perm. (order by
inch)
Hose Fitting
Bushing
Bolt, Hex Head 5/16-18 x 1.0” Zinc
Nut, Serrated Flange 5/16-18
Oil Filter
Tee, 3/4” O-Ring x JIC x 1/2” Hose
Nut, Hex Elastic Stop 1/4-20
Cap, Hydraulic Tank
Insert, Filler Neck
O-Ring
Oil Reservoir Assembly (incl. 24, 27, 39)
Elbow, 90 Degree .38” Hose
Bushing, .56” Dia. Viton
Hose Clamp, 0.69” Dia.
Hose, 3/8” ID, Pushlock (order by inch)
Screw, Phillips Head, 1/4-20
Cap
Fuel Tank Assembly (incl. items 23 & 24)
Clamp, Hose
Elbow, 90 Degree, 1/2” x 1/2”
Elbow, 90 Degree, 5/8” x 1/2” (35BV Only)
Bushing, 7/8”-14 JIC x 3/4”-16 O-Ring
Support Bracket, Fuel Tank
Nut, 5/16-18 Serrated Flange
Bolt, Carraige 1/4-20 x 3/4”
Elbow, 90 Degree
Bushing, .78” Dia. Viton
Strap, Hydraulic Tank
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
423485
481611
483676
48572-04
04001-59
04030-02
04060-09
04001-08
482505
422694
481793
482695
483101
04021-09
04001-32
482696
483100
482497
04021-09
04043-04
423524
423525
Support Bracket, Hydraulic Tank
Hose Assembly, Pump (27CH, 27KA,
29DFI)
Hose Assembly, Pump (35BV Only)
Union, 3/4”-16 JIC x 3/4”-16 O-Ring
Bolt, Hex Head, 1/4-20 x 1-1/4”
Lockwasher, 1/4” Spring
Roll Pin, Spring 3/16 x 3/4”
Bolt, Hex Head 5/16-18 x 3/4”
Cooler, Oil
Clamp Plate, Pump Control
Block, Pump Control
Pump, Left Hand, BDP-16A-410
Pump, Left Hand, BDP-16A (31BV)
Nut, Hex, Elastic Stop 3/8-16
Bolt, Hex Head, 3/8-16 x 1-1/4”
Pump, Right Hand, BDP 16A-307
Pump, Right Hand, BDP-16A (31BV)
Cap, Fuel Tank W/Gauge
Nut, Hex Elastic Stop 3/8-16
Flatwasher, 3/8” (.391 x .938 x .105”)
Grade 8
Mounting Bracket - LH, Oil Cooler
Mounting Bracket - RH, Oil Cooler
** Available through the individual engine manufacturer.
