Section 8
ENGINE & ATTACHING PARTS - 35HP BRIGGS & STRATTON
Ref.
No.
Part No. Description
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
422593
04017-05
482860
**
04110-01
483537
483017
** 483045
04002-18
04030-04
04001-21
04021-09
04001-32
451454
04003-12
04019-03
424691
451949
424805
424804
04011-15
Muffler Guard (35BV, Briggs & Stratton)
Screw, Hex Serrated Flange 1/4-20 x 3/4”
Muffler, Briggs & Stratton
Screen Weldment, Radiator (Avail. only through B & S)
U-Nut, 1/4-20
Hour Meter
Oil Drain, (BV Only)
Engine, Briggs & Stratton 35HP V-Twin Liquid-Cooled (Avail. only through B & S)
Bolt, M10-1.50 x 25mm Grade 8.8
Lockwasher, 3/8” Spring
Bolt, Hex Head 3/8-16 x 1-3/4”
Nut, Hex Elastic Stop 3/8-16
Bolt, Hex Head 3/8-16 x 1-1/4”
Plate, Engine Mounting
Bolt, Carriage 5/16-18 x 3/4”
Nut, Hex Serrated Flange 5/16-18
Rear Cover
Heatshield Weldment, Muffler
Heatshield Ext., LH
Heatshield Ext., RH
Screw, #10 x 1/2” Self Tap
** Available through the individual engine manufacturer.
