Scag Power Equipment STT61V-27KA Lawn Mower User Manual



48
R
Section 8
72A CUTTER DECK
Ref.
No.
Part No. Description
Ref.
No.
Part No. Description
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
461865
04003-40
04019-04
481625-01
481632
04003-26
422478
04017-27
04043-06
04021-05
461296
04001-12
04001-11
04021-22
04020-09
451240
04001-41
04003-12
04001-154
04063-08
04063-01
04043-04
04001-11
04021-10
04001-172
48100-15
04030-03
04040-15
04041-07
04021-09
04001-62
04001-54
43503
04001-136
461663
43589
481024
481022
43644
43312
43296
481025
43297
481035
48114-04
48677
Cutter Deck, 72” Advantage w/Decals
Bolt, Carriage 7/16-14 x 1-1/4”
Nut, Hex Serrated Flange 3/8-16
Wing Nut, 3/8-16
Anti-Scalp Wheel
Bolt, Carriage 3/8-16 x 4”
Anti-Scalp Wheel Bracket
Bolt, Hex Serrated Flange 3/8-16 x 1”
Flatwasher, 5/8” Hardened
Locknut, 3/8-16 Center Lock
Discharge Chute, 72” Adv.
Bolt, Hex Head 5/16-18 x 1.75” - Front
Bolt, Hex Head 5/16-18 x 1.50” - Rear
Nut, Hex Elastic Stop 5/16-18 Grade 8
Nut, 5/8-11 UNC
Push Arm Shaft
Bolt, Hex Head 5/8-11 x 9.50”
Bolt, Carriage 5/16-18 x .75”
Bolt, Hex Head 5/16-18 x 4.75”
Key, 1/4 x 1/4 x 2”
Key, 1/4 x 1/4 x 1.25”
Flatwasher,3/8” (.39 x .938 x .105”) HD
Bolt, Hex Head 5/16-18 x 1-3/4”
Nut, Hex Serrated Flange 5/16-18
Bolt, Hex Head 1/4-20 x 1” Grade 8
Bushing, .376” I.D. Oilite
Lockwasher, 5/16”
Flatwasher, 5/16” (.375 x .875 x .083”)
Flatwasher, 3/8” (.391 x .938 x .105”)
Nut, Hex Elastic Stop 3/8-16
Bolt, Hex Head 3/8-16 x 3-1/4”
Bolt, Hex Head 3/8-16 x 3”
Pivot, Idler - Short
Bolt, Hex Head 3/8-16 x 1.50” Grade 8
Spindle Assembly
Spindle Shaft
Seal, Top
Bearing Assembly
Spindle Housing
Spacer, Outside
Spacer, Inside
Seal, Bottom
Spindle Bushing, Bottom
Nut, Special 1-1/16-18
Grease Fitting
Relief Fitting, Tapered Spindle
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
482245
48038
482882
482486
481980
45944
48926
48141
461842
48224
483215
461929
482747
424798
422677
422708
461516
423795
04020-16
48763
04001-79
483704
482745
04110-03
04021-13
423958
482295
43590
04003-23
04040-11
04021-11
483167
04003-12
04040-04
04021-04
483174
04021-10
43763
424799
04001-154
Spring, Discharge Chute
Guide, Roller
Cutter Blade, 24.5”
Gearbox Assembly, Deck Drive
Belt, Cutter Deck Drive, 72”
Roller Shaft
Tapered Hub, 1-1/8” Bore
Tapered Hub, 1” Bore
Idler Arm, Cutter Deck
Bearings, Ball
Pulley, Idler
Lever Assembly, Deck Level (Incl. 77)
Pulley, 6.95” O.D. - 72”
Mounting Plate, RH Gearbox
Belt Cover, LH - 72”
Belt Cover, RH - 72”
Pusharm (includes items 44, 63 & 64)
Baffle, Custom Cut 72A
Nut, Hex Head 5/8-18 UNF
Rod End, 5/8” Male RH Thread
Bolt, Hex Head 5/8-11 x 4-1/2”
Spring, Cutter Deck
Pulley, 6.35” O.D. - 72”
U-Nut, 3/8-16
Nut, Hex Elastic Stop 5/8-11
Discharge Baffle 72”
Wheel, Anti-Scalp
Spacer, Spindle Bottom
Bolt, Carriage 3/8-16 x 1”
Flatwasher, 7/16” (.50 x 1.25 x .083”)
Nut, Elastic Stop 7/16-14
Bolt, Deck Adjust
Bolt, Carraige 5/16-18 x 3/4”
Flatwasher, 5/16”
Nut, Center Lock 5/16-18
Wear Pad
Nut, Elastic Stop 5/16-18
Spacer, Gearbox Mount
Mounting Plate, LH Gearbox
Bolt, Hex Head 5/16-18 x 4-3/4”
