Scag Power Equipment STT61V-27KA Lawn Mower User Manual



50
R
Section 8
CUTTER DECK CONTROLS
Ref.
No.
Part No. Description
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
461929
481764
481765
481766
04020-27
04020-28
04021-09
482429
43391
43487
43526
43527
45904
45905
04021-05
422381
423509
422346
46975
48100-14
481428
481598
424504
04020-09
04019 -03
04040-09
04041-14
48114-04
04061-07
04030-07
04004-44
04067-09
04050-08
04021-07
04105-01
423463
04014-03
481547
48540
04001-20
04019-04
04050-10
04001-74
04003-04
04009-02
Lever Assembly, Deck Level
Link, Deck Lift
Rod End, Female - 1/2-20 RH
Rod End, Female - 1/2-20 LH
Nut, Jam 1/2-20 RH
Nut, Jam 1/2-20 LH
Nut, 3/8-16 Elastic Stop
Slide Weldment, Height Adjustment
Spacer, Decklift Pedal
Pin, Decklift
Swivel Joint, LH
Swivel Joint, RH
Bellcrank Weldment, LH Rear
Bellcrank Weldment, RH Rear
Locknut, 3/8-16 Center Lock
Guide, Short
Guide, Long
Lockplate, Decklift
Deck Latch (Includes items 20 & 21)
Bushing, .502” ID.
Grip, Deck Latch
Spring, Helper (61” & 72” Cutter Decks Only)
Foot Pedal, Height Adjustment
Nut, Hex 5/8-11
Nut, Hex Serrated Flange 5/16-18
Flatwasher, 5/8” (.656 x 1.312 x .095”)
Flatwasher, 1” (1.062 x 1.50 x .048”)
Grease Fitting
Cotter Pin, 3/16 x 1”
Lockwasher, 5/8”
Stud, 5/8-11 x 22.0”
Ring Pin, 1/2 x 3.06”
Ring, Retaining 1” External “E”
Nut, Hex Elastic Stop 1/2-13
Capscrew, 5/8-11 x 1-1/2”
Bracket, Cutting Height Adjustment
Screw, Cap 5/16-18 x 3” FHHS
Lanyard, Deck Height Pin
Chain
Bolt, Hex Head 3/8-16 x 1-1/2”
Nut, Hex Serrated Flange 3/8-16
Ring, Retaining 1/2” External “E”
Bolt, Hex Head 1/2-13 x 3”
Bolt, Carriage 5/16-18 x 1”
Bolt, Shoulder 1/2 x 3/4”
