Scag Power Equipment STT61V-27KA Lawn Mower User Manual



52
R
Section 8
SHEET METAL COMPONENTS
Ref.
No.
Part No. Description
Ref.
No.
Part No. Description
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
451481
04001-09
43606
04041-07
461967
483384
04001-45
04021-09
*
48903
421274
04003-12
423308
04029-01
04019-03
04003-01
48661
43584
04003-04
482622
04021-09
461991
04019-04
04017-27
451480
423489
04021-09
04001-19
04001-125
04021-13
481559
04021-20
481657
482028-01
451450
451957
451825
451451
451452
451453
481025
04021-07
45934
451416
04001-134
04001-167
43581
43583
9277
9278
04001-01
04001-01
423674
482943
482948
Fender Weldment, RH
Bolt, Hex Head, 5/16-18 x 1, Zinc
Spacer
Flatwasher, 3/8 (.391 x .938 x .105”)
Seat Plate Weldment
Seat Assembly w/Armrest and Seat Belt
Bolt, Hex Head 3/8-16 x 2.0”
Nut, Elastic Stop 3/8-16
Battery (not avail. through Scag)
Pad, Battery Cover
Cover, Battery
Bolt, Carriage 5/16-18 x 3/4”
Plate, Battery Box
Wing Nut, 1/4-20 x 3/4”
Nut, Hex Serrated Flange 5/16-18
Bolt, Carriage 1/4-20 x 6”
Rubber Pad
Spacer, Caster Wheel
Bolt, Carriage 5/16-18 x 1”
Seal
Locknut, 3/8-16, Elast. Stop
Main Frame
Nut, Hex Serrated Flange 3/8-16
Screw, Hex Serrated Flange 3/8-16 x 1”
Fender Weldment, LH
Foot Plate
Nut, Hex Elastic Stop 3/8-16
Bolt, Hex Head 3/8-16 x 1”
Bolt, Hex Head 5/8-11 x 4”
Nut, Hex Elastic Stop 5/8-11
Cap, Grease
Nut, Hex Elastic Stop 1.0-14
Bearing W/Race
Plug, 1/4-28 THD Form
Extention Weldment, Caster 52V (LH)
Extention Weldment, Caster 52V (RH)
Extention Weldment, Caster 61V (LH)
Extention Weldment, Caster 61V (RH)
Extention Weldment, Caster 72A (LH)
Extention Weldment, Caster 72A (RH)
Seal, 2.00” OD. x 1.625” Bore
Nut, Hex Elastic Stop 1/2-13
Yoke Weldment, Caster (52V)
Yoke Weldment, Caster (61V & 72A)
Bolt, Hex Head 1/2-13 x 7-1/2” (52V)
Bolt, Hex Head 1/2-13 x 9-1/2” (61V &
72A)
Sleeve, Caster Wheel (52V)
Sleeve, Caster Wheel (61V, 72A)
Wheel Assy, 52V (Incl. items 20, 54, 55)
Wheel Assy, 61V, 72A (Incl. 20, 54, 55)
Bolt, Hex Head 1/4-20 x 3/4”
Bolt, Hex Head 1/4-20 x 3/4”
Mounting Bracket, STT Cup Holder
Lumbar Kit
Knob Kit
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
48566
482940
9240
482502
462045
462046
461908
461909
461910
461911
482614
482615
482618
482617
482616
482621
48114-10
481389
43462
04060-01
483428
482950
482945
482946
482941
482944
482948
482952
482942
424819
Cable, Seat Stop
Back Cushion Kit
Cup Holder Assembly
Seat Adjustment, Track Set
Caster Wheel Assembly (Incl. 31 thru 43)
52V (LH)
Caster Wheel Assembly (Incl. 31 thru 43)
52V (RH)
Caster Wheel Assembly (Incl. 31 thru 43)
61V (LH)
Caster Wheel Assembly (Incl. 31 thru 43)
61V (RH)
Caster Wheel Assembly (Incl. 31 thru 43)
72A (LH)
Caster Wheel Assembly (Incl. 31 thru 43)
72A (RH)
Back Cushion Cover
Seat Cushion Cover
Armrest, Right Hand
Armrest, Left Hand
Armrest Cover
Bearing w/ Race
Grease Fitting
Spring, Seat
Pin Retainer, Spring
Roll Pin, Spring 5/32 x 3/4”
Suspension Seat Assembly w/seat belt
Armrest Only
Armrest Assembly Kit, LH
Armrest Assembly Kit, RH
Seat Cushion Kit
Seat Drain Kit (Incl. with Seat Cushion)
Weight Adjustment Kit
Knob Kit
Seat Adjustment, Track Set
Shock Absorber Kit
Guard, Fuel Line
