Section 6: Specifications & Capacities
RCD1884 Rotary Cutters 326-355M
12/15/15
Table of Contents
Section 6: Specifications & Capacities
RCD1884 Model
Specifications & Capacities
Machine Weight with
Dual Laminated Tailwheels
Dual Solid Tailwheels
900 lbs.
905 lbs.
Hitch Category l with clevis type lower links and floating top linkage
Quick Hitch adaptable
Cutting Width 84"
Overall Width 86 9/16"
Overall Length 80 9/16"
Offset Distance to the Right 10"
Deck Height at Rear 11 5/8"
Cutting Height 2" - 12"
Cutting Capacity 1 1/2" Diameter
Recommended Tractor PTO HP 35-60 HP
PTO Speed 540 rpm
Gearbox 60 Hp main gearbox & 45 HP side gearbox
With speed-up beveled gears, cast iron housing, and 1.67" output shaft
Gearbox Lubricant EP 80-90W oil
Gearbox oil Capacity Main Gearbox
Side Gearbox
4.7 pints
3.5 pints
Deck Construction All welded deck
Deck Material Thickness 10 Gauge
Side Skirt Material Thickness 10 Gauge
Skid Shoe Construction 3/16" Weld-on with mounting holes for adding optional bolt-on replaceable shoes
Stump Jumper 10 Gauge x 24" Round dish pan with 1" x 4" x 19 1/2" blade bar
Blades (4) 1/2" x 4" x 16" Heat treated alloy steel free-swinging suction blades
Blade Overlap 5"
Blade Bolts Keyed with harden flat washers & lock nuts.
Blade Tip Speed 11,693 fpm
Main Driveline ASAE Category 3
Main Driveline Protection 2 plate slip clutch
Tailwheel Mount Caster fork with 360 degree swivel
Tailwheel Optional two 15" laminated tire or two 4" x 16" molded rubber tire.
Front Guard Optional 4" x 6" molded rubber or single chain guard
Rear Guard Standard metal band or optional metal extended guard
