Introduction:
RCD1884 Rotary Cutters 326-355M
12/15/15
Table of Contents
Owner Assistance
The Online Warranty Registration or Warranty
Registration card should be completed by the dealer at
the time of purchase. This information is necessary to
provide you with quality customer service.
The parts on your Rotary Cutter have been specially
designed by Land Pride and should only be replaced with
genuine Land Pride parts. Contact a Land Pride dealer if
customer service or repair parts are required. Your Land
Pride dealer has trained personnel, repair parts, and
equipment needed to service the implement.
Serial Number
Model No. _____________Serial No. _______________
For quick reference and prompt service, record model
number and serial number in the spaces provided above
and again on warranty page 35. Always provide model
number and serial number when ordering parts and in all
correspondences with your Land Pride dealer. Refer to
Figure 1 for location of your serial number.
Figure 1
Further Assistance
Your dealer wants you to be satisfied with your new
Rotary Cutter. If for any reason you do not understand
any part of this manual or are not satisfied with the
service received, the following actions are suggested:
1. Discuss the matter with your dealership service
manager making sure that person is aware of any
problems you may have and has had the opportunity
to assist you.
2. If you are still not satisfied, seek out the owner or
general manager of the dealership, explain the
problem, and request assistance.
3. For further assistance write to:
Land Pride Service Department
1525 East North Street
P.O. Box 5060
Salina, KS. 67402-5060
E-mail address
lpservicedept@landpride.com
30976
Land Pride welcomes you to the growing family of new
product owners.
This Rotary Cutter has been designed with care and built
by skilled workers using quality materials. Proper
assembly, maintenance, and safe operating practices will
help you get years of satisfactory use from this machine.
Application
The Land Pride RCD1884 offset Rotary Cutter is
designed and built to clear grass, weeds, and light brush
up to 1 1/2 inches in diameter from areas under orchard
and grove trees, beneath over-hanging hedge rows, or
under fence lines and guard railings. The unit offsets 10"
to the right with rear mounted 360 degree rotating
tailwheels making it well suited for operation on gentle
slopes and mildly contoured approaches immediately
adjacent to ponds, lakes, streams, drainage ditches, and
roadways. The seven foot cutting width and 2" to 12"
cutting height makes it well suited for mowing pastures,
set aside acres, and row crop fields.
The RCD1884 is compatible with 35 to 60 horsepower
tractors with a category I three point hitch and is Quick
Hitch adaptable. It operates at 540 rpm PTO speed and is
protected with a category 3 driveline with a 2-plate slip
clutch. Supplied with the cutter is a stump jumper, front
rubber shield and rear metal band shield.
See “Specifications & Capacities” on page 30 and
“Features & Benefits” on page 32 for additional
information and performance enhancing options.
Using This Manual
•
This Operator’s Manual is designed to help familiarize
the operator with safety, assembly, operation,
adjustments, troubleshooting, and maintenance. Read
this manual and follow the recommendations to help
ensure safe and efficient operation.
• The information contained within this manual was
current at the time of printing. Some parts may change
slightly to assure you of the best performance.
• To order a new Operator’s or Parts Manual, contact
your authorized dealer. Manuals can also be
downloaded, free-of-charge, from our website at
www.landpride.com.
Terminology:
“Right” or “Left” as used in this manual is determined by
facing the direction the machine will operate while in use
unless otherwise stated.
Definitions:
IMPORTANT: A special point of information related
to the following topic. Land Pride’s intention is this
information must be read & noted before continuing.
NOTE: A special point of information that the
operator should be aware of before continuing.
Introduction:
