DCA85USJ2 60 HZ GENERATOR • OPERATION AND PARTS MANUAL — REV. #1 (03/22/11) — PAGE 89
ENCLOSURE (1) ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 M2413002202 BASE 1
2 M2363300703 ENVIRONMENTAL TANK 1
3 0016910030 HEX HEAD BOLT 12
4 0603306797 PLUG 1
5 M2423002102 FRONT FRAME 1
5A M2493108903 ACOUSTIC SHEET 1
6 M2423002202 FRONT FRAME 1
6A M2493108903 ACOUSTIC SHEET 1
7 0601851739 GROMMET 1
8 0015908020 HEX HEAD BOLT 27
9 0016910025 HEX HEAD BOLT 6
10 M3131400404 HOSE COVER 1
11 0016906020 HEX HEAD BOLT 7
12 M3131400503 HOSE COVER 1
13 0015905020 HEX HEAD BOLT 8
14 M3423500104 BRACKET 1
15 0016906016 HEX HEAD BOLT 6
16 M3423200704 DUCT COVER 2
17 0016906020 HEX HEAD BOLT 14
18 M2310200904 SHROUD BRACKET 1
19 0016906016 HEX HEAD BOLT 11
20 M2423300704 DISCHARGE GUIDE 1
20A M2493109004 ACOUSTIC SHEET 1
21 0016908020 HEX HEAD BOLT 4
22 M2423203203 COVER, FRONT FRAME 1
22A M2493109103 ACOUSTIC SHEET 1
23 M2423203303 FRONT LOUVER 1
24 0019206016 HEX HEAD BOLT 6
25 0019208020 HEX HEAD BOLT 4
26 0016908020 HEX HEAD BOLT 4
27 M2433001202 CENTER FRAME 1
27A M2493200504 ACOUSTIC SHEET 1
28 0010114040 HEX HEAD BOLT 4
28A 0030014000 HEX NUT 4
28B 0040014000 WASHER, LOCK 4
28C 0041214000 WASHER, FLAT 8
29 0010120050 HEX HEAD BOLT 4
29A 0030020000 HEX NUT 4
29B 0040014000 WASHER, LOCK 4
29C 004122000 WASHER, FLAT 8
30 M2493505204 ROOF PANEL 1
30A M2493505204 ACOUSTIC SHEET 1
31 M2463200102 ROOF PANEL 1
31A M2493506203 ACOUSTIC SHEET 1
32 M3463200704 BACK PLATE 2
33 0016906016 HEX HEAD BOLT 12
