DCA85USJ2 60 HZ GENERATOR • OPERATION AND PARTS MANUAL — REV. #1 (03/22/11) — PAGE 27
Select Units
1. Starting at the single or four engine parameter display
touch the “Menu Button”.
2. The main menu will pop up on the display. Use the
arrow buttons to scroll through the menu until the
“Select Units” is highlighted.
3. Once the “Select Units” menu item has been highlighted
touch the “Enter Button” to access the “Select Units”
function.
4. Use the arrows to highlight the desired units. “English”
for imperial units i.e. PSI,”F or Metric kPa, Metric Bar
for IS units i.e. kPa, Bar, “C".
COOL
1800 RPM
0
1500
3000
TEMP
ENG RPM
98%
14.2
57 PSI
1000 RPM
LOAD RPM
BATT VOLT
ENG RPM
OIL PRES
GO TO 1-UP DISPLAY
STORED CODES
G
ADJUST BACKLIGHT
ENGINE CONF
SETUP 1-UP DISPLAY
SETUP-4-UP DISPLAY
SELECT UNITS
GO TO 1-UP DISPLAY
STORED CODES
G
ADJUST BACKLIGHT
ENGINE CONF
SETUP 1-UP DISPLAY
SETUP-4-UP DISPLAY
SELECT UNITS
ENGLISH
ESPANOL
FRANCAIS
DEUTSCH
DIAGNOSTIC DISPLAY
5. Touch the “Enter Button” to select the highlighted units.
6. Touch the “Menu Button” to return to the “Main Menu”
.
7. Touch the “Menu Button” to exit the Main menu and
return to the engine parameter display.
SETUP 1-UP DISPLAY
1. Starting at the single engine parameter display, touch
the “Menu Button”.
2. The main menu will pop up on the display. Use the
“Arrow Buttons” to scroll through the menu until the
“Setup 1-up Display” is highlighted.
ENGLISH
METRIC KPA
METRIC BAR
ENGLISH
METRIC KPA
METRIC BAR
*
GO TO 1-UP DISPLAY
ENGINE CONF
SETUP 1-UP DISPLAY
SETUP-4-UP DISPLAY
SELECT UNITS
STORED CODES
G
ADJUST BACKLIGHT
98%
14.2
57 PSI
1000 RPM
LOAD RPM
BATT VOLT
ENG RPM
OIL PRES
COOL
1800 RPM
0
1500
3000
TEMP
ENG RPM
98%
14.2
57 PSI
1000 RPM
LOAD RPM
BATT VOLT
ENG RPM
OIL PRES
GO TO 1-UP DISPLAY
STORED CODES
G
ADJUST BACKLIGHT
ENGINE CONF
SETUP-4-UP DISPLAY
SELECT UNITS
SETUP 1-UP DISPLAY
