60” DECK GROUP
Ref.
No.
Qty.
Part No. Description Req'd.
Ref.
No.
Qty.
Part No. Description Req'd.
1 103-0422-01 Deck wldmt, 60....................... 1 50✫❖ 1-633012 Jackshaft, deck drive ...............1
103-0676 Deck wldmt, 60 w/decals........ 1 51 3217-11 Nut, 5/8-11 hex ........................2
2 1-634619 Housing w/ring, spacer, brg.... 3 52 323-20 Screw, 3/8-16 x 3 ¼.................1
3 3256-24 Washer, 3/8 SAE.................... 3 53✫❖ 1-633014-01 Bracket, jackshaft.....................1
4✫❖ 1-513208 Washer, disc Spring............... 3 54✫❖ 3230-1 Bolt, 5/16-18 x 3/4 Carr...........6
1-513208 Washer, disc Spring............... 4 55
✫❖ 1-513013 Housing, flange........................4
5 1-303334 Washer, 5/16 disc spring ....... 1 56✫❖ 1-513012 Bearing w/lock collar & ss........2
6 32128-20 Nut, 5/16-18 whizlock............. 2 57∗ 103-1140 Cutter housing complete..........3
✫❖
32128-20 Nut, 5/16-18 whizlock............. 14 58✫❖ 3231-22 Bolt, 3/8-16 x 1 carr .................4
7 1-602913-01 Baffle wldmt, discharge .......... 1 59 103-1072-01 Strut wldmt, deck .....................2
8 322-2 Screw, 5/16-18 x 5/8 .............. 5 60✫❖ 1-323533 Spacer shv/brg.........................3
9 1-603299 Roller, antiscalp...................... 6 1-323533 Spacer shv/brg.........................4
10 3290-357 Nut, 3/8-16 whizlock............... 6 61 1-633029 Spherical rod end.....................2
✫❖
3290-357 Nut, 3/8-16 whizlock............... 10 62 ✫❖ 1-803050 Setscrew, 5/16 x 3/4sqhdcp.....1
11 1-373034 Washer, pivot ......................... 8 63 327-11 Screw, 5/8-11 x 5.....................2
12 1-603602 Bushing, roller ........................ 6 64 3253-8 Lockwasher, 5/8 reg.spring......2
13 98-5975 Washer, 3/8 disc spring ......... 10 65 302-19 Zerk, 1/4-28 straight.................4
14 98-5961 Screw, 3/8-16 x 4 gr 8 .......... 6 66 1-632199-01 Pin wldmt, deck strut ................2
15 1-632939-01 Chute, discharge 60”.............. 1 67✫❖ 3219-6 Nut, 5/8-18 hex ........................5
16 322-5 Screw, 5/16-18 x 1 ................. 2 3219-6 Nut, 5/8-18 hex ........................6
17 3296-29 Nut, 5/16-18 nylock ................ 4 68 3257-32 Key, # 61 Woodruff..................3
18 1-633084-01 Shield, belt 60” ....................... 2 69★ 1-633701 Sheave, Blade drive.................3
19 1-323385 Knob, belt shield..................... 6
70★✫❖
1-513016 Bearing ....................................6
20 1-322110 Belt guide wldmt..................... 1
★
1-513016 Bearing ....................................8
21 103-0862 Screw, 5/8-11 x 2 ¾ gr 8 ........ 3 71 1-323532 Housing, bearing......................3
22 323-11 Screw, 3/8-16 x 2 1/4 ............. 2 72✫❖ 1-323528 Spacer, bearing .......................3
23 1-303537 Stud, belt shield...................... 2 1-323528 Spacer, bearing .......................4
24 3256-3 Washer 5/16 std flat ............... 6 73✫❖ 1-633573 Guard, brg bottom....................3
25 1-323417 Washer, rubber ...................... 2 1-633573 Guard, brg bottom....................4
26 1-633151 Spring, extension.................... 1 74✫❖ 32120-8 Snap Ring................................3
27 1-632119-03 Arm wldmt, deck idler............. 1 32120-8 Snap Ring................................4
28 1-513034 Bearing, pivot ......................... 2 75 103-0584 Spindle.....................................3
29 1-634244 Arm wldmt/brg sub-assy......... 1 76 1-633483 Blade, notched air foil ..............3
30 1-603044 Bushing, idler pivot................. 1 1-613250 Blade, solid air foil....................3
31 302-40 Zerk, 1/4-20 90°. .................... 1 1-613111 Blade, low lift............................3
32 3256-4 Washer, 3/8 std flat ................ 3
✦
1-613112 Blade, mulching .......................3
33 3296-39 Nut, 3/8-16 nylock .................. 20 103-1580 Blade, bahia.............................3
34 323-13 Screw, 3/8-16 x 2 3/4 ............. 1 77✫❖ 1-634546 Jackshaft S/A...........................1
35 1-633109 Idler pulley 6.00 dia flat .......... 2 78∇✫ 103-1081 Strut wldmt S/A .......................2
36 3234-11 Bolt, 3/8-16 x 1 whizlock......... 1
∇❖
103-1106 Strut wldmt S/A .......................2
37 1-633456 Bushing, Idler ......................... 2 79 103-0280 Housing, Jackshaft .................1
38 323-8 Screw, 3/8-16 x 1 ½ ............... 18 80 103-0136 Sheave, Jackshaft Double.......1
39 32128-37 Nut, 7/16-14 whizlock............. 16 103-0137 Sheave, Jackshaft Double ......1
40 1-603805 Idler pulley 5.06 O.D. V .......... 1 81✫❖ 1-643393 Jackshaft .................................1
41 1-633127 Belt, blade drive 60” deck....... 1 82 103-0700 Jackshaft Assy.........................1
42 1-633447 Chain...................................... 4 103-0701 Jackshaft Assy.........................1
43 1-800811 Screw, 7/16-14 x 1 ½ .............. 8 83 103-0680 Complete Deck Assy
44 322-3 Screw, 5/16-18 x ¾ ................ 2 (Air-cooled except 26HP Koh EFi) 1
45★✫ 1-303498 Sheave, 6.13 OD..................... 1 103-0681 Complete Deck Assy
★❖
1-643292 Pulley, split 6.71 OD................ 1 (23 & 27 HP Kaw liq-cooled & 26 HP Koh EFI ) 1
46★✫ 1-633010 Pulley, split 6.30 OD………….. 1 84 322-6 Screw. 5/16-18 x 1 ¼...............1
★❖
1-643292 Pulley, split 6.71 OD................ 1 85 323-6 Screw. 3/8-16 x 1.....................4
47 ✫❖ 30-1710 Setscrew, 5/16-18 x 1sqhdcp.. 1 86 103-1192 Asm,Jackshaft housing w/brgs 1
48 ✫❖ 1-803022 Setscrew,5/16-18x5/8sqhdcp . 2 87 103-0865 Washer,disc spring..................3
49✫❖ 1-807264 Key, 1/4 sq x 2 5/8 .................. 1
★ Use antiseize on bore of sheaves and bearings. Exmark red touch up spray paint - P/N 1-850337
∗ Cutter housing complete includes sheave, washer, & nut. Use Pro-lock Nut Type (P/N 1-840022) on setscrews.
✦ Requires installation of Micro-Mulch accessory for proper mulching. Mulch kit P/N MK604
∇ Strut subassemblies have same components, they are assembled to different lengths from center to center. PN 103-1081 = 15.31”; PN 103-1106 =
15.00”
Reference the picture on the next page to determine if your unit uses Jackshaft Type A or B:
✫ A component used with Jackshaft Type A on all air-cooled units except 26 HP Kohler EFI.
❖ A component used with Jackshaft Type A on 23 & 27HP Kawasaki liquid-cooled units and 26HP Kohler EFI air cooled.
A component used with Jackshaft Type B on all air-cooled units except 26 HP Kohler. Reference picture on next page.
A component used with Jackshaft Type B on 23 & 27 HP Kawasaki liquid-cooled units and 26 HP Kohler EFI air-cooled.
