AIR-COOLED ENGINE DECK GROUP
Ref.
No.
Qty.
Part No. Description Req'd.
Ref.
No.
Qty.
Part No. Description Req'd.
1
1-643315 Baffle, Engine Cooler............. 1
33
32128-33 Nut, whizlock 1/4-20 ............. 5
2
1-303335 Plastic tie ............................. 1
34
1-633396 Clip, loom .56........................ 1
3
1-523420 Bumper, rubber .................... 2
35
1-809076 Screw, M6-1.0 x 45mm
4
322-6 Screw, Cap 5/16x1 ¼
(Warner) 1 (23 hp & 25 hp Koh) .................. 2
5
1-633630 Grommet
(all clutches) ........... 2 32144-57 Screw, 5/16-18x1.75
6
1-603610 Wshr, spring disc
(all clutches). 2 (23 hp Kaw & 26 hp Koh) .......... 2
7
1-633615-03 Guard, rear engine ............... 1
36
1-323235 Washer, disc spring
8
1-633543-03 Strap, clutch
(all clutches) ....... 1 (23 hp & 25 hp Koh only)........... 2
9
103-0662 Clutch w/tie
(23HP) ................ 1
37
1-323236 Spacer ................................... 2
103-0665 Clutch w/tie (25&26HP)........... 1
38
1-633545 Spacer, Grommet (all clutches) . 2
10
1-633453 Spacer
(23 HP) ..................... 1
39
1-633988 Spacer, clutch anchor (Warner).1
1-633179 Spacer (25 & 26 HP) ............... 1
40
3296-29 Nut, nyloc 5/16-18 (Warner) .... 1
11
1-634308 Shield, lift – subassy
(Koh) .... 1 3296-29 Nut, nyloc 5/16-18 (Ogura) ...... 2
103-1301 Shield, lift – subassy (Kaw).... 1
41
3256-63 Washer, 3/16 std. .................. 6
12
103-1308 Shield, engine ...................... 1
42∇
1-543232 Nipple, pipe 3/8 NPT
(Koh) .... 1
13
1-633300-03 Shield, lift
(Koh) ..................... 1
43∇
1-303428 Elbow, 3/8 NPT (Koh) ............ 1
103-1304-03 Shield, lift (Kaw)..................... 1 44 322-14 Screw, 5/16-18 x 3.0 (Ogura) .. 1
14
1-634796 Shield (LH) - subassy
(Koh) ... 1 45 1-633082 Spacer, clutch anchor (Ogura)… 1
103-0241 Shield (LH) - subassy (Kaw) .. 1 46 322-7 Screw, 5/16-18 ½ (Ogura) ....... 1
15
1-633301 Shield, heat
(Koh).................. 2 47 1-643179 Spacer, clutch (Ogura) ............ 1
103-0243 Shield, heat (Kaw) ................. 2 48 1-641212 Clutch w/tie (Ogura)................. 1
16
1-633795-03 Baffle, engine (LH) ............... 1 49 1-643180 Keeper, clutch
(Ogura) ............ 1
17
1-643313-03 Shield, muffler ..................... 1
50
1-807261 Key, ¼ x ¼ x 2.0
(Ogura) ........ 1
18 1-644316 Shield (RH) - subassy (Koh)…. 1 51*
103-1594 Muffler,kit 26hp EFI Kohler... 1
103-0242 Shield (RH) - subassy (Kaw)… 1
103-1595 Muffler,kit 23hp Kaw............. 1
19
1-523285 Clip, shield
(Koh) ................... 2
52
9266934 Screw, 5/16-18x.5
1-523285 Clip, shield (Kaw)................... 4 (23 hp Kaw & 26 hp Koh) .......... 2
20
1-633794-03 Baffle, engine (RH)............... 1
53
324-2 Screw, 7/16-14x.75 g5
21 322-19 Screw, 5/16-18x4 (Warner) .... 1
(23 hp Kaw & 26 hp Koh) .......... 2
22
321-4 Screw, 1/4-20 x ¾ ................ 10
54
3253-6 Washer, Lock 7/16
23
1-613235 Washer
(Warner) ................... 4 (23 hp Kaw & 26 hp Koh) .......... 2
1-613235 Washer (25 hp Ogura) ............ 5
55
33014-00 Nut, Hex M8 1.25
24
323-6 Screw, 3/8-16 x 1 ................. 8 (23 hp Kaw & 26 hp Koh) .......... 4
323-6 Screw, 3/8-16 x 1 (26hp Koh)… 9
56
1-805005 Washer, Lock 5/16hvy
25³ 3212-10 Screw, 7/16-20x2 ½(all clutches)1 (23 hp Kaw & 26 hp Koh) .......... 4
26
1-803035 Rivet, 3/16 x ¼
(Koh)............. 11
579
103-0152 Keeper, Clutch ..................... 1
1-803035 Rivet, 3/16 x ¼ (Kaw) ............ 13
58
1-653291 Gasket (Koh) ......................... 2
27
3296-42 Nut, nyloc 1/4-20 .................. 6 1-653313 Gasket
(Kaw) .......................... 2
28
1-643264-03 Bracket, guard top................ 2
59
103-1513 Arrester,Spark (1.25) ............ 1
29
3256-2 Washer, 1/4 std.................... 4 (26 hp Koh EFI & 23 hp Kaw)
30
3256-3 Washer, 5/16 std
(all clutches). ... 1
60
103-1514 Clamp,Muffler (1.38) ............. 1
31
32128-20 Nut,whzlck 5/16-18
(Warner)… 1 (26 hp Koh EFI & 23 hp Kaw)
32
3290-357 Nut, whzlck 3/8-16 ................ 8
3290-357 Nut, whzlck 3/8-16 (26hp Koh)… 9
∇ Use a Teflon Pipe Sealant or equivalent on threads.
Use Pro-Lock, Nut Type (P/N 840022, .5ml tube) on clutch bolt.
* The muffler for 23 & 25 HP Kohler units comes with the engine.
9 For 23 HP Kawasaki air-cooled units only
Exmark black touch up spray paint - gloss black
Kohler Replacement Parts List Kawasaki Replacement Parts List
(Refer to Engine Owner’s Manual) (Refer to Engine Owner’s Manual)
Description Kohler Part No.
Description Kawasaki Part No.
Engine Oil Filter 5205002 Engine Oil Filter 49065-2078
Air Precleaner (23hp Engine) 2408302 Air Filter 11029-7002
(For 25hp Engine) 2408305 .........
Air Filter (For 23hp Engine) 4708303
(For 25hp Engine) 2408303
(For 26hp EFI Engine) 2508301
Safety Filter (For 26hp EFI Engine) 2508304
