KAWASAKI LIQUID-COOLED ENGINE DECK GROUP (cont.)
Ref.
No.
Qty.
.Part No. Description Req'd.
Ref.
No.
Qty.
Part No. Description Req'd.
1 1-633864-03 Screen, Radiator Intake .... 1 33 1-633898-03 Rib, Bottom ...................... 2
2
1-803069 Screw,10-24X.75 BHSCap 4
34
1-633877-03 Bar, Latch Hook................ 2
3
3256-14 Washer, Flat Std #10........ 16
35
1-643189 Keeper, Rubber Latch ...... 2
4 3296-2 Nut, Nyloc #10-24 ............. 4 36 1-633896-03 Bar, Rad. Mnt. Frame....... 2
5
1-633857 Hood, Engine Gray........... 1
37
323-7 Screw,Cap HH 3/8-16x1-1/44
✫
103-1044 Hood, w/decals ................ 1
38
323-9 Screw,Cap HH 1/4-20x1 1/22
6
322-4 Screw,Cap HH 5/16-18x7/8 8
39
103-0897-03 Plate, Side Rad. Mnt. RH . 1
7
3256-23 Washer, Flat SAE 5/16 ..... 21
40
1-632984-03 Brace, Radiator-LH
(23 hp).1
8 3296-29 Nut, Nyloc 5/16-18 ............ 4
103-0107-03 Brace, Radiator-LH
(27 hp).1
9
1-633885-03 Plate, Hood Hinge............. 2
41
1-632985-03 Brace, Radiator-RH .......... 1
10
1-632986-03 Hinge, Shackle wld ........... 2
42
1-633878-03 Crossbar........................... 1
11
32128-20 Nut, Whizlock 5/16-18 ...... 37
43
1-643087-03 Deflector, Air..................... 1
12
322-3 Screw,Cap 5/16-18x3/4 ... 24
44
3269-3 Pop Rivet- Stl 3/16x.250... 4
13
1-808285 Pin, Clevis 3/8x1 1/8 ......... 2
45
49-2040 Screw, Tapping1/4-20x.75 2
14 3256-24 Washer, Flat SAE 3/8 ....... 12 46
1-643096-03 Plenum, Air intake
(23 hp) .. 1
15
1-806003 Pin, Hair Cotter .080 #2 .... 2 103-0110-03 Plenum, Air intake
(27 hp) .. 1
16
1-643106-03 Angle, Rad. Trim Side RH. 1 47 103-0221 U-bolt
(72” deck, 27 hp) ......... 2
17
1-643108-03 Angle, Rad. Trim Bottom .. 1 1-643147 U-bolt
(all except 72”deck, 27hp) 2
18
1-643107-03 Angle, Rad. Trim Top........ 1
48
1-643150-01 Weight Bar
(52” deck, 23 hp).4
19
1-643105-03 Angle, Rad. Trim Side LH . 1 103-0217-01 Weight Bar
(60” deck, 23 hp).2
20
1-643187 Seal, Trim - 20" Length. .... 2 103-0217-01 Weight Bar
(60” deck, 27 hp).3
21
1-643186 Seal, Trim - 14" Length ..... 2 103-0885-01 Weight Bar
(72” deck, 27 hp).1
22 103-0896-03 Plate, Side Rad. Mnt. LH .. 1 49
3256-4 Washer, flat Std 3/8.......... 4
23
1-643188 Latch, EPDM Rubber........ 2
50
3296-39 Nut, Nyloc 3/8-16.............. 4
24
923786 Pop Rivet. ......................... 8
51
1-634308 Shield, lift - subassembly.. 1
25
322-5 Screw, Cap 5/16-18x1 ...... 9
52
1-633300-03 Shield, lift .......................... 1
26 1-632873-03 Radiator Mount weld-rear . 1 53
1-803035 Rivet, Alum. 3/16x1/4 ....... 3
27 1-633886-03 Bumper, Rear.................... 1 54
103-1308 Shield, engine................... 1
28
3296-42 Nut, Nyloc 1/4-20 .............. 6
55
32128-33 Nut, Whizlock 1/4-20 ........ 2
29
323-6 Screw, Cap Hex 3/8-16x1. 6
56
321-4 Screw, 1/4-20x3/4............. 4
30
1-523420 Bumper, rubber................. 2
57
3256-2 Washer, 1/4 std ................ 6
31
3290-357 Nut, Whizlock 3/8-16......... 10
58
1-803072 Rivet, Bulbex .19 x1.07 .... 17
32
1-633897-03 Rib, Top ............................ 2
59
1-303435 Washer, Spring Disc .25 .. 5
Exmark black touch up spray paint – gloss black
✫ Hood only comes with black logo decal, side decals need to be ordered separately.
