COMMON ENGINE DECK GROUP
Exmark black touch up spray paint - gloss black
Ref.
No.
Qty.
.Part No. Description Req'd.
Ref.
No.
Qty.
Part No. Description Req'd.
1 98-5975 Washer, spring disc 3/8...... 5
12 1-633166 Pulley, idler.......................... 1
2
302-40 Zerk, 1/4-20 (90º)................ 1
13 1-633173 Belt, mule drive ................... 1
3
1-513034 Bearing................................ 2
14
1-632469 Arm, idler w/bushings.......... 1
4
1-603401 Spacer, spring..................... 1
15
323-11 Screw, 3/8-16 x 2 1/4.......... 2
5
3256-4 Washer, 3/8 ........................ 3
16
323-9 Screw, 3/8-16 x 1 3/4 (Koh) 5
6
1-603050 Spacer ................................ 1 323-9 Screw, 3/8-16 x 1 3/4 (Kaw) 1
7
1-603384 Bushing, idler pivot.............. 1
17
323-13 Screw, 3/8-16 x 2 3/4 ......... 1
8
1-603402 Spring, mule idler................ 1
18
1-800805 Screw, 3/8-16 x 3 1/2.......... 1
9
1-603496 Bushing, idler ...................... 2
19
3296-39 Nut, nyloc 3/8 ...................... 1
10
1-603805 Pulley, idler ......................... 1
20
3256-24 Washer, 3/8 sae.................. 3
11
1-632468-03Arm, idler ............................ 1
21
3290-357 Nut, whizlock 3/8-16............ 10
