Exmark 103-0656 Lawn Mower User Manual



3
52” DECK GROUP
Ref.
No.
Qty.
Part No. Description Req'd.
Ref.
No.
Qty.
Part No. Description Req'd.
1 103-0332-01 Deck wldmt, 52"....................... 1 48 1-803022 Setscrew,5/16-18x5/8sqhdcp ....2
103-0675 Deck wldmt, 52" w/decals........ 1 49 1-807264 Key, 1/4 sq x 2 5/8 .....................1
2 3256-24 Washer, 3/8 SAE..................... 3 50 1-633012 Jackshaft, deck drive .................1
3 1-323533 Spacer, shv/brg ....................... 3 51 103-1140 Cutter housing complete............3
1-323533 Spacer, shv/brg ....................... 4 52 323-20 Screw, 3/8-16 x 3 1/4 .................1
4 1-513208 Washer, disc spring................. 3 53 1-633014-01 Bracket, jackshaft ......................1
1-513208 Washer, disc spring................. 4 54 3230-1 Bolt, 5/16-18 x 3/4 Carr.............6
5 1-303334 Washer, 5/16 disc spring......... 1 55 1-513013 Housing, flange.......................... 4
6 32128-20 Nut, 5/16-18 whizloc................ 14 56 1-513012 Bearing w/lock collar & ss..........2
7 1-602913-01 Baffle wldmt, discharge ........... 1 57 1-633573 Guard, Brg bottom .....................3
8 322-2 Screw, 5/16-18 x 5/8................ 5 1-633573 Guard, Brg bottom .....................4
9 1-603299 Roller, antiscalp....................... 6 58 3231-22 Bolt, 3/8-16 x 1 carr....................4
10 3290-357 Nut, 3/8-16 whizlock ................ 12 59 103-1072-01 Strut wldmt, deck .......................2
3290-357 Nut, 3/8-16 whizlock ................ 8 60 1-634619 Housing w/ring, spacer, & brg.... 3
11 1-373034 Washer, pivot .......................... 8 61 1-633029 Spherical rod end.......................2
12 1-603602 Bushing, roller ......................... 6 62 1-803050 Setscrew, 5/16-18 x .75sqhd .....1
13 98-5975 Washer, 3/8 disc spring........... 10 63 327-11 Screw, 5/8-11 x 5.......................2
98-5975 Washer, 3/8 disc spring........... 14 64 3253-8 Lockwasher, 5/8 reg.spring........2
14 98-5961 Screw, 3/8-16 x 4 gr 8 ............ 6 65 302-19 Zerk, 1/4-28 straight...................4
15 103-0345-01 Chute, discharge 52”............... 1 66 1-632199-01 Pin wldmt, deck strut.................. 2
16 322-5 Screw, 5/16-18 x 1................... 3 67 3219-6 Nut, 5/8-18 hex ..........................5
17 3296-29 Nut, 5/16-18 nyloc ................... 4 3219-6 Nut, 5/8-18 hex ..........................6
18 1-633357-01 Shield, belt 52” ........................ 2 68 3257-32 Key, # 61 Woodruff....................3
19 1-323385 Knob, belt shield...................... 6 69 1-633701 Sheave, blade drive...................3
20 1-322110 Belt guide wldmt ...................... 1 70 1-513016 Bearing ......................................6
21 103-0862 Screw, 5/8-11x2 3/4 gr 8 ......... 3 1-513016 Bearing ......................................8
22 323-11 Screw, 3/8-16 x 2 1/4............... 2 71 1-323532 Housing ,bearing........................3
23 1-303537 Stud, belt shield....................... 2 72 1-323528 Spacer, bearing .........................3
24 3256-3 Washer 5/16 std flat ................ 4 1-323528 Spacer, bearing .........................4
25 1-323417 Washer, rubber........................ 2 73 323-7 Screw, Hex cap 3/8x1 1/4……...18
26 1-633151 Spring, extension..................... 1 74 32120-8 Snap Ring ..................................3
27 1-632119-03 Arm wldmt, deck idler .............. 1 32120-8 Snap Ring ..................................4
28 1-513034 Bearing, pivot........................... 2 75 103-0584 Spindle.......................................3
29 1-634244 Arm wldmt/brg sub-assy.......... 1 76 1-633482 Blade, notched air foil. ...............3
30 1-603044 Bushing, idler pivot .................. 1 1-613251 Blade, solid air foil......................3
31 302-40 Zerk, 1/4-20 90°....................... 1 1-633485 Blade, low lift..............................3
32 3256-4 Washer, 3/8 std flat ................. 3
1-633484 Blade, mulching .........................3
33 3296-39 Nut, 3/8-16 nylock.................... 20 103-1578 Blade, bahia...............................3
34 323-13 Screw, 3/8-16 x 2 3/4............... 1 77 1-634546 Jackshaft S/A.............................1
35 1-633109 Idler pulley 6.00 dia flat ........... 2 78 103-1081 Strut wldmt S/A ..........................2
36 3234-11 Bolt, 3/8-16 x 1 whizlock.......... 1 103-1106 Strut wldmt S/A ..........................2
37 1-633456 Bushing, Idler .......................... 2 79 1-643393 Jackshaft....................................1
38 3217-11 Nut, 5/8-11 hex........................ 2 80 103-0135 Sheave, Jackshaft .....................1
39 32128-37 Nut, 7/16-14 whizlock .............. 16 103-0185 Sheave, Jackshaft .....................1
40 1-603805 Idler pulley 5.06 O.D V ............ 1 81 103-0280 Housing, Jackshaft ....................1
41 1-633366 Belt, blade drive 52” Deck....... 1 82 103-0698 Jackshaft S/A.............................1
42 1-633447 Chain....................................... 4 103-0699 Jackshaft S/A.............................1
43 1-800811 Screw, 7/16-14 x 1-1/2 ............ 8 83 103-0678 Complete deck asy (LZ25KC524) 1
44 322-3 Screw, 5/16-18 x 3/4 ........................... 2 103-0679 Complete deck asy (LZ23LKA524)1
45 1-403087 Sheave, blade drive 6.75 OD .. 1 84 323-6 Screw, 3/8-16 x 1 ...................... 4
46 1-633010 Pulley, split sheave 6.30 OD ... 1 85 103-1192 Asm,Jackshaft housing w/brgs…1
47 30-1710 Setscrew, 5/16-18 x 1sqhdcp .. 1 86 103-0865 Washer,disc spring....................3
Use Pro-lock Nut Type (P/N 1-840022 .5 ml. tube) on setscrews. Use antiseize on bore of sheaves and bearings.
Cutter housing complete includes sheave, washer, and nut. Exmark red touch up spray paint - P/N 1-850337
Requires installation of Micro-Mulch accessory for proper mulching. Mulch kit P/N MK524
Strut subassemblies have same components, they are assembled to different lengths from center to center.
PN 103-1081=15.31”;PN 103-1106=15.00”
Reference the picture on the next page to determine if your unit uses Jackshaft Type A or B:
A component used with Jackshaft Type A on LZ25KC524 & LZ23LKA524 units.
A component used with Jackshaft Type B on LZ25KC524 units.
A component used with Jackshaft Type B on LZ23LKA524 units
