FRONT FRAME GROUP
Exmark red touch up spray paint - P/N 850337
∇ Components are standard on Kohler 26 HP EFI units & all 72” decks, they are an optional kit for other models
PN 103-0149.
Ref.
No.
Qty.
Part No. Description Req'd.
Ref.
No.
Qty.
Part No. Description Req'd.
1 1-632518-01 Frame wldmt, front 52” ....... 1 29 3217-11 Nut, 5/8-11 regular............. 8
1-632513-01 Frame wldmt, front 60”....... 1
30
1-633441 Swivel, deck mount...............4
1-642046-01 Frame wldmt, front 72”....... 1
31
3256-7 Washer, 5/8 std flat ........... 4
2
302-19 Zerk, 1/4-28 straight ........... 5
32
1-633064 Spring,
deck support (52” &60”)2
3
103-1490-01 Floorpan ............................ 1 1-643015 Spring, deck support (72”).. 2
4
1-633553 Pad, anti skid...................... 3
33 3218-6 Jam nut, 5/8-11.................. 4
5
1-634312 Lever w/grip....................... 1
34 1-543513 Cap, grease ........................ 2
1-632324-03 Lever wldmt, lift ................. 1
35 1-543509 Bearing cone, tapered roller 4
6
1-633295 Grip, lift lever ...................... 1
1-543508 Bearing cup, tapered roller . 4
7
103-1500-03 Arm wldmt, deck lift............ 1 36
1-543511 Seal, grease........................ 2
8
1-633325 Spring, compression .......... 1 37 1-642111-01 Caster wldmt........................ 2
9
3256-24 Washer, 3/8 SAE flat.......... 1 38 3296-51 Nut, 3/4-10 nylock................ 2
10
3296-39 Nut, nylock 3/8-16 .............. 5 39 1-633508 Washer, spring disk............. 6
11
32151-103 E-ring.................................. 5
40
325-24 Screw
, ½-13x9 .....................2
12
1-633068 Arm, deck lift ...................... 2
41
1-811010 Plug ..................................... 2
13
3272-10 Cotter pin, 1/8 x 3/4............ 2
42
103-0069 Caster wheel assy ............... 2
14
1-808284 Clevis pin, 3/8 x 1............... 2
43
3296-45 Nut, 1/2-13 nylock
(light thin) .. 2
15
1-633889-01 Plate, deck lift..................... 1
44
1-633959 Spacer, front caster ............. 2
16
1-632899-01 Plate wldmt, deck lift .......... 1
45
103-0063 Seal, bearing........................ 4
17
1-633082 Bushing, lift lever ................ 1 46 1-633585 Bearing cone........................ 4
18
1-633080 Bushing, lift lever ................ 1
47
1-633581 Spacer, bearing.. ................. 4
19 323-13 Screw, 3/8-16 x 2 3/4 ......... 1 48
103-0065 Wheel & tire assy ................ 2
20
1-633097 Hitch pin w/lanyard ............. 1 1-523009 Tire, 13x6.5-6 4 ply ............. 2
21
1-806005 Hairpin cotter (serv only) .... 1 103-0071 Wheel .................................. 2
22
323-9 Screw, 3/8-16 x 1 3/4 ......... 2 1-633584 Bearing cup.......................... 4
23
98-5975 Washer, 3/8 disc spring......12 49
∇ 32128-20 Nut, whizlock 5/16-18……… 2
24 3290-357 Nut, whizlock 3/8-16 ..........15
50
∇ 1-543161 Pad, pedal............................ 2
25
323-6 Screw, 3/8-16 x 1 ............... 3
51∇
103-0147-01 Lever wldmt, deck lift ........... 1
26
323-7 Screw, 3/8-16X1 1/4...........12 52
∇ 1-643220 Strap .................................... 1
27
3256-29 Washer, 7/8 SAE flat.......... 4
53∇
322-7 Screw, 5/16-18x1 1/2 ........... 2
28
1-633096 Rod, deck lift....................... 2
