2002 Dimension One Spas Export Owner’s Manual
Using the Programmable Digital Controller
To initiate the programming sequence at any time, push and hold the Program Pad for 3 seconds. If, within 10
seconds, you do not proceed with the hot tub programming, the hot tub will automatically exit the programming
sequence and revert to the pre-set factory default settings. To exit the programming sequence at any time, do not
press any pad for 10 seconds. Any programming changes made up to that point is saved.
Clock Set
Push and hold the Program Pad for 3 seconds to engage the time setting mode. The time screen will appear with
“hours” (__.00) flashing on and off. Push the Up Pad or Down Pad to increase or decrease the number until the
desired hour appears in the Digital Display. When the desired number is displayed, push the Light Pad to accept
the selection and change the flashing number to the “ten minute” place (12:_0). Adjust the number with the Up or
Down Pads in the same manner as the hour number. When the desired number is displayed, push the Light Pad to
accept the selection and change the flashing number to the “minute” place (12:1_). Adjust this number with the Up
or Down Pad in the same manner as the hour number. When the desired number is displayed, push the Light Pad
to accept the selection and change the flashing number to a flashing AM or PM indicator. Adjust the indicator with
the Up and Down Pads. When the desired indicator is displayed, push the Program Pad to accept the selection and
enter the Filter Cycle Start Time programming mode.
Filter Cycle Start Time
To adjust the filter cycle start time, push the Up or Down Pads and Light Pads as done in the Clock Set
programming mode to choose a time. Once the desired time is displayed, push the Program Pad to accept the
selection and move into the Filter Cycle Duration programming mode.
Note
You will be prompted later to set the filter cycle duration and the number of filter cycles. Be sure
to keep this in mind when programming your filter cycle start time. During the filter cycle, JET 1
will activate at high speed for the duration of the filter cycle.
Filter Cycle Duration
To adjust the filter cycle duration, push the Up or Down Pads to cycle through the choices of 60, 90, 120, 150 or
180 minutes (the default is 60). Once the desired time is displayed, push the Program Pad to accept the selection
and move into the Number of Filter Cycles programming mode.
Caution
Long and/or numerous filter cycles could cause overheating of the hot tub - especially in hot
climates.
Number of Filter Cycles
To adjust the number of filter cycles per day, push the Up or Down Pad to cycle through the number of filter
cycles - 1, 2, 3 or 4 (the default is 2). Once the desired number of cycles is displayed, push the Program Pad to
accept the selection and move into the Temperature Unit Selection programming mode.
