Dimension One Spas - Bay Collection - Owner’s Manual
12
Adjusting
Temperature
From the Temperature screen, push the up or
down arrow on the 5-Key Context Keypad to
enter the Setpoint screen. In this screen, use
up and down to select the desired temperature.
Press Accept to save the changes.
Summer Mode
During hot weather, normal filtering can cause
the spa to exceed the set temperature, which
stops the circulation pump so the spa can cool.
If the spa is not filtering enough during hot
weather, it is possible to put it into Summer
Mode to allow the pump to keep running.
To enter Summer Mode, adjust the set point to
the lowest possible temperature, 59°F (15°C),
and continue to hold the down arrow on the 5-
Key Context Keypad. The temperature value
will be replaced by “Summer.”
Light Operation
Press the light button once to enter Brilliant Mode. All lights are turned
ON in the spa. To switch to Candle Mode press the light button once,
then push it again just after “LIGHT OFF” begins to scroll off of the
display. The lights in the air valves, tile line, and fountain are on; the
spa light is off. To switch to Fountain Mode, press the light button
once, and then push it again just after “LIGHT OFF” begins to scroll off
of the display. The fountain light is on; all other spa lights are off. Push
the light button once, then press it again just after “LIGHT OFF” begins
to scroll off the screen to switch back into Brilliant Mode. To lock in
your favorite light color, push and hold the light button until all lights in
the spa blink off, then on. To unlock and return to the color wheel, hold
down the light button until the lights blink off and on again.
Standby Mode
To enter Standby mode, hold down the center
key on the 5-Key Context Keypad while on the
home screen for 5 seconds. This mode
disables all automatic and manual functions so
the pumps do not accidentally start while you
are cleaning the filters. The spa stays in
standby mode for 30 minutes. To reactivate
the spa, press exit.
