5. Installation and Connections

Connecting an External Monitor

Youcanconnectaseparate,externalmonitortoyourprojectortosimultaneouslyviewonamonitorthecomputer

analogimageyou’reprojecting.

NOTE:

• TheAUDIOOUTminijackdoesnotsupportHeadphoneterminal.

• Whenaudioequipmentisconnected,theprojectorspeakerisdisabled.

• ThesignaloutputfromtheMONITOROUT(COMPUTER)ofthisprojectorisforprojectingimageonexclusiveonedisplay.

• Whennosignalisappliedover3minutesintheconditionofprojectorstandbywhenNETWORKSTANDBYissetintheStandby

mode,outputfromtheMONITOROUTorAUDIOOUTterminalwillbestopped.Inthiscasepulloutthecomputercableandset

itbackafterinputtingvideosignal

Monitoroutandsleepmode:

• TheMONITOROUT(COMP.)connectorwillnotworkwhen[NORMAL]isselectedfor[STANDBYMODE].

 TheMONITOROUT(COMP.)connectorwillworkonlyinthesleepmode.

 ApplyingasignalfromtheCOMPUTERINconnectorwillputtheprojectorinthesleepmode,whichallowsyoutousetheMONI-

TOROUT(COMP.)connectorandtheAUDIOOUTminijack.SoundfromtheMICinputjackwillbeoutputtotheAUDIOOUTmini

jack.

 Thesleepmodeisoneofthestandbymodes.Thesleepmodecannotbeselectedfromthemenu.

• Inthenetworkstandbymode,soundforthelastviewedcomputerorvideosourcewillbeheard.

 BNC-to-COMPUTERINterminalconvertedsignalwillnotbeoutputinthestandbymodeandsleepmode.

Computer

cable (VGA)

(supplied)

Stereo mini-plug audio cable (not

supplied)

Computer cable (VGA)

(not supplied)

Stereo mini-plug audio

cable (not supplied)
