Item
Specifications
Lens
Shooting speed
Shooting area
Limit of focus adjustment
Zoom
Focusing
Iris
Image pick-up element
Total picture elements
Effective picture element
Sync. system
Resolution
Analog RGB output
Composite-video output
S-video output
White balance
Gamma adjustment
Video output selection
Electronic shutter speed
f=5.8 ~ 58mm(10-time zoom) F2.8
15 frames/sec
350mm x 260mm (13.8 X 10.2 in.) max., 38mm x 28mm (1.5 X 1.1 in.) min.
At the range of stage surface - 100mm from the stage surface
(Camera positioned sideways with no close-up lens) 1.1m -
Powered (with double speed function)
Auto/manual
Auto/manual
1/3" CCD
1077(H) x 788(V) (approx. 850,000 pixels)
1024 (H) x 768(V)
Internal
Analog RGB output More than 600 TV lines (Horizontal)
More than 600 TV lines (Vertical)
Video output More than 400 TV lines (Horizontal)
More than 400 TV lines (Vertical)
Signal frequency
XGA
Horizontal frequency
60.023kHz
Vertical frequency
75.029kHz
(1024 x 768@75Hz) VESA conformable
NTSC/PAL conformable
NTSC/PAL conformable
Full auto
Provided (OFF : 1.0/ON : 0.6)
Provided (NTSC/PAL)
Provided (50/60)
Item
Specifications
Power source
Power consumption
AC outlet
DC output terminal
Outside dimensions
Weight
Input selection
Output terminal
Input terminal
Ext. control terminal
AC120V 60Hz
Power 43W
1 pce. (Max. 400W/Unswitched)
DC12V (Max. 0.9A)
400mm(W) X 660mm(D) X 168mm(H) (15.7 X 26.0 X 6.6 in.) - When folded
700mm(W) X 542mm(D) X 625mm(H) (27.6 X 21.3 X 24.6 in.) - When set up
10 kgs (22.1 lbs) (main body only)
Internal/RGB1/RGB2
RGB output
Composite-video output
S-video output
RGB inputs
RS-232C
1
1
1
2
1
DSUB 15P connector female
RCA pinjack/75Ω unbalanced (NTSC/PAL)
Mini DIN 4P connector/75Ω unbalanced (NTSC/PAL)
DSUB 15P connector female
DSUB 9P connector male
