9
Head
OFF
ON
60
50
Part Name Function
Reference Page
31 Gamma selection switch Gamma selection is used for adjusting the luminance shade with the
device to connect RGB output to. Generally, it is recommended to
use ON when connecting to the CRT monitor; use OFF when
connecting to the LCD projector. The luminance shade may not
match depending on the type of projector. Use ON in such a case.
32 Shutter selection switch In an area where power frequency is 50Hz, using the unit with
flicker correction switch set to [60] may cause flickering due to
illumination of AC power discharge tube, such as a fluorescent or a
mercury lamp.
Using the unit the flicker correction switch set to [50] may reduce
the flickering.
This switch is factory-set to 60Hz.
31. Shutter selection switch
30. Gamma selection switch
