14
Signal assignment (DSUB 15P shrinking terminal)
1
2
3
4
5
Pin No.
Name
Video output (Red)
Video output (Green)
Video output (Blue)
NC
GND
Name
GND (Red)
GND (Green)
GND (Blue)
NC
GND
Name
GND
NC
Horizontal synchronizing signal
Vertical synchronizing signal
NC
6
7
8
9
10
Pin No.
11
12
13
14
15
Pin No.
RGB input signal
10
9
8
7
6
12345
1112131415
Signal assignment
Input signal
Video signal
Horizontal synchronizing signal
Vertical synchronizing signal
Composite synchronizing signal
Analog 0.7V(p-p) 75
TTL level (positive/negative polarity)
TTL level (positive/negative polarity)
TTL level (positive/negative polarity)
DSUB 15P shrinking terminal (Female)
Pin arrangement
1
2
3
4
5
Pin No.
Name
Video input (Red)
Video input (Green)
Video input (Blue)
NC
GND
Name
GND (Red)
GND (Green)
GND (Blue)
NC
GND
Name
GND
NC
Horizontal synchronizing/
composite synchronizing signal
Vertical synchronizing signal
NC
6
7
8
9
10
Pin No.
11
12
13
14
15
Pin No.
RGB output signal
