5. VARIOUS FUNCTIONS
Lighting
The upper lighting unit for presenting material such as printed
matter and 3-D object, and the baselight for presenting
transparent material, such as slide are built in the Presenter.
Depending on the material to be presented, press the button
[UPPER] or [BASE] on the front operation panel or wireless
remote control. The indication lamp will blink for a few
seconds, and then the fluorescent lamp will light up.
To turn OFF the lamp, press the button for the respective
lamp.
It has been so set before shipment that the lighting unit lights
up when the power supply is turned ON.
Notes: - It is impossible to have the upper lighting unit and
the baselight lit up together.
- When the lightness of the material surface is not
sufficiently high or a 3-D object is presented, a
sharp image with good color rendering can be
obtained with the upper lighting unit.
- To reduce glare, attach enclosed stickers, as
shown, to the outside ends, of toplights.
Input selection
The respective images from two different AV sources, such as
PC and ELMO Presenter [HD-80XG], connected to Video-in
Terminal 1 [INPUT] [RGB1] and Video-in Terminal 2
[INPUT] [RGB2] respectively, can be alternately presented on
the Monitor by simply selecting the AV source by pressing the
input selection button without changing cable connections.
Press the input selection button [RGB1] / [RGB2] on the
front operation panel or wireless remote control.
When the built-in camera button [MAIN] on the front
operation panel or wireless remote control is pressed, the
image by the built-in camera is resumed.
Front operation panel
Wireless remote control
Front operation panel
Wireless remote control
