34
ITEM PA RT DE SCRIPTIO N NO.
NO. NO. REQ’D
ITEM PART DESCRIPTIO N NO.
NO. NO. REQ’D
Use only genuine Walker replacement parts. Effective Date 04-01-99
MAIN BODY COMPONENTS
Spout/Deflector Assembly
1 5640 Grommet (1/4 x 3/8) 1
2 5641 Handle, Deflector Position Control 1
3 5685-1 Decal, Danger (#23555) 2
4 5604 Spout Deflector 1
(Includes Item # 2)
5 5639 Deflector Gasket 1
6 5617-1 Spout Discharge Guard 1
7 5603-2 Spout 1
5603-6 Spout Assembly
*
(Includes Items # 1-12, F005, F020, F029,
F032, F034, F049, F050, F061, F091, F177,
F178, F236 & F310)
8 5618 Spout Rotation Stop 1
9 5229 Extension Spring (1/2 x 2-1/4) 1
10 5616 Handle, Spout Position Control 1
11 5642 Spring, Deflector Handle 1
12 5643 Plastic Tip, Handle 1
Housing/Frame Assembly
13 5747-5 Safety Tread (6 x 11-1/2) 2
14 5607 Cover (Includes Item # 13) 1
15 5850-1 Handle Grip 1
16 5800 Decal, Walker Mower (4 x 7-1/2) 1
17 5685-2 Decal, Warning (#23569) 1
18 5610 Scraper Blade 1
(Includes Items # F004 & F172) 1
19 5605 Auger Guard 2
20 5611 Skid Shoe (Heat Treated)
*
5611-1 Skid Shoe Kit (Optional) 1**
(Includes Items # 20, F009 & F169) ***
21 5629-2 Gauge Wheel 2
5629 Snowblower Gauge Wheel Assembly 2
(Includes Items # 21, 22, 23, F034,
F168, F170 & F209)
22 5830 Grease Fitting 7
23 5629-1 Wheel Bracket 2
24 5743-2 Extension Spring (1-1/2 x 7-3/4) 2
25 5653 Chain Shackle (5/16) 4
(Includes Item # F069)
26 5655 Lift Chain (4-1/2) 2
27 5628-2 Lift Bracket 2
28 5747-4 Safety Tread (3-1/4 x 4-1/2) 2
29 5606 Chain Guard 1
30 NS Housing & Frame 1
♦
(Includes Items # 3, 16, 17 & 28)
31 5654 Lift Trigger 1
32 5227-1 Extension Spring (1/2 x 4) 1
Fasteners
F004 1/4-20 Keps Nut 7
F005 1/4-20 ESNA Nut 3
F009 5/16-18 Whiz Locknut 6
***
F020 5/16-18 ESNA Nut 6
F029 1/4-20 x 1/2 Hex Bolt 4
F031 1/4-20 x 5/8 Hex Bolt 2
F032 1/4-20 x 3/4 Hex Bolt 2
F034 5/16-18 x 3/4 Hex Bolt 5
F035 5/16-18 x 1-1/4 Hex Bolt 2
F049 5/16 SAE Washer 4
F050 1/4 SAE Washer 1
F061 1/4 Internal Star Lock Washer 5
F069 3/32 x 1/2 Cotter Pin 4
F091 5/16-18 x 5/8 Hex Bolt 1
F093 5/16-18 x 1 Hex Bolt 2
F111 1/8 x 3/4 Cotter Pin 1
F134 AN960816L Washer 4
♦♦
F168 5/16 Split Lock Washer 2
F169 5/16-18 x 1 Carriage Bolt 6
***
F170 5/16 x 1 x 7/64 Washer 2
F172 1/4-20 x 3/4 Carriage Bolt 7
F173 5/16-18 x 3/4 Carriage Bolt 4
F176 #14 x 1/2” Sheet Metal Screw 6
F177 5/16 x 1-1/2 Fender Washer 2
F178 1/4 x 1 Fender Washer 6
F209 .765 x 1.312 x .032 Washer 4
F236 1/4-20 x 1-3/4 Hex Bolt 1
F310 5/16 x 1-1/8 x 3/16 Washer 1
* Service Part Only
** May be purchased as a factory-installed option or as a kit for
dealer installation. Contact your Walker dealer. Kit Replaces
Part 5629-2, and Includes Items # F009 & F169.
*** Six (6) F009 furnished with Standard Assembly. Installation of
Skid Shoe Kit includes an additional six (6) F009 and six (6)
F169.
♦
Housing and Frame shown only for models prior to S/N 99-1042.
For models with S/N 99-1042 and later, refer to detail shown in
AUGER AND DRIVETRAIN COMPONENTS (Page 36).
♦♦
Average of four (4) F134 used per assembly. Adjust as required.
