Maintenance Instructions LUBRICATION
30
LUBRICATION
Proper lubrication is an important maintenance pro-
cedure. It reduces wear and makes the machine
quieter and easier to operate.
Engine Oil
Engine Break-In Oil
No special break-in oil is required. The engine is
serviced with 10W-30, Service Class SG oil from the
factory. Change the oil after the initial engine break-
in period of 5 hours. Thereafter, change oil after
every 100 hours of operation or more often in ex-
tremely dusty or dirty conditions.
Checking Engine Crankcase Oil Level
Check the engine crankcase oil level before use and
after each 5 hours of continuous operation.
IMPORTANT: The importance of checking and
maintaining the proper crankcase oil level can-
not be overemphasized. Check the oil level BE-
FORE EACH USE.
1. Park the mower on a level surface with the en-
gine stopped. Also, make sure the engine is
cool and oil has had time to drain into the sump
[allow at least five (5) minutes after stopping
the engine].
IMPORTANT: NEVER check or add oil with the
engine running.
2. Before removing the dipstick, clean the area
around the dipstick to keep any dirt or debris out
of the engine.
3. Remove the dipstick, wipe off with a clean rag,
then reinsert the dipstick into the tube without
screwing it in.
4. Remove the dipstick again and check the oil lev-
el on the dipstick. The oil level should be be-
tween the FULL and LOW mark on the dipstick.
IMPORTANT: DO NOT operate engine without
a sufficient oil supply in the crankcase. DO NOT
operate with the oil level below the lower mark or
above the upper mark on the dipstick.
5. If additional oil is needed, refer to Specifications
for proper crankcase lubricant. Fill up to, but
not above, the upper mark on the dipstick.
IMPORTANT: DO NOT overfill the crankcase
(oil above “F” mark) as this CAN result in en-
gine overheating, loss of power, and possible
engine damage.
Changing Engine Crankcase Oil/Oil Filter
Change the engine crankcase oil after every 100
hours of operation and replace the oil filter every
other oil change (every 200 hours of operation or
more often in extremely dusty or dirty conditions).
1. Park the mower on a level surface with the en-
gine stopped. The engine oil should be warm
before draining. If not warm from operation, start
the engine and run a few minutes to warm the oil.
2. Before removing the dipstick and oil fill cap,
clean the area around them to keep any dirt or
debris out of the engine.
3. Remove the dipstick, oil fill cap, and unscrew
the oil drain plug 4-1/2 revolutions (to prevent
the drain plug from coming out completely, do
not exceed 4-1/2 turns). Drain oil into a suitable
container. Be sure to allow ample time for com-
plete drainage.
Oil Drain, Dipstick (Oil Fill),
and Oil Filter Location
WARNING
DO NOT attempt to lubricate the machine
with the engine running. Disengage the
PTO clutch, shut off the machine, and re-
move the ignition key.
Oil Drain
Oil Filter
Oil Fill/
Dipstick
