Specifications
5
MODEL
MT 20.0 HP MT 25.0 HP
TIRE PRESSURE
Deck Caster Wheel 20 PSI (137 kPa) 20 PSI (137 kPa)
Drive 15 PSI (103 kPa) 15 PSI (103 kPa)
Rear 20 PSI (137 kPa) 20 PSI (137 kPa)
DIMENSIONS (Tractor and Mower)*
Length 91 in. (231 cm) 91 in. (231 cm)
Width 49 in. (124 cm) 49 in. (124 cm)
Height 44 in. (112 cm) 44 in. (112 cm)
Wheel Base (Tractor) 42-1/4 in. (107 cm) 42-1/4 in. (107 cm)
Tread Width (Tractor) 29-3/4 in. (76 cm) 29-3/4 in. (76 cm)
MOWER DECK
Width of Cut SD/GHS 42 or 48 in. (107 or 122 cm) 42 or 48 in. (107 or 122 cm)
Cutting Height 1 to 4 in. (3 to 10 cm) 1 to 4 in. (3 to 10 cm)
Height Adjustment 7 Positions - 1/2 in. (1 cm)
Increment Hitch Pins Installed
in Multi-Position Deck Support
7 Positions - 1/2 in. (1 cm)
Increment Hitch Pins Installed
in Multi-Position Deck Support
Blade Size (Typical)
42 in. (107 cm) SD 22 in. (56 cm)
2 in. (5 cm) Center Overlap
(Two Blades, CW Rotation)
22 in. (56 cm)
2 in. (5 cm) Center Overlap
(Two Blades, CW Rotation)
48 in. (122 cm) GHS 25 in. (64 cm)
2 in. (5 cm) Center Overlap
(Two Blades, Counter Rotate)
25 in. (64 cm)
2 in. (5 cm) Center Overlap
(Two Blades, Counter Rotate)
Deck Suspension Torsion-Flex Frame with
Caster Wheels and
Counterweight Springs
Torsion-Flex Frame with
Caster Wheels and
Counterweight Springs
CURB WEIGHT (Approximate)
SD Tractor Only 660 lb (299 kg) 665 lb (302 kg)
GHS Tractor Only 760 lb (345 kg) 765 lb (347 kg)
Tractor and Mower* 965 lb (438 kg) 970 lb (440 kg)
*Dimensions and weight shown are for 48 in. (122 cm) GHS Model (typical).
Dimensions for Tractor and Mower with 42 in. (107 cm) deck are:
Length = 88 in. (224 cm)
Width = 43 in. (110 cm)
For SD Models, subtract 7 in. (18 cm) from the height.
Deck weight for 48 in. (122 cm) Tilt-Up deck = 205 lb (93 kg). Deck sizes range from 42 to 62 in.
(107 to 157 cm), with corresponding deck weights ranging from 170 to 300 lb (77 to 136 kg).
Optional (9.5 Bushel) Grass Catcher adds approx. 5 lb (2 kg) and 5 in. (13 cm) in Height
