924916KG251004
HYDRAULIC CIRCUIT DIAGRAM
ITEM NO.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
DESCRIPTION. PART NO:
Axial Piston Pump - Variable Displacement. -
Charge Pump. -
Relief Valve - Charge Pump -18.5 bar. -
Mechanical Control. -
Relief Valve - Forward Travel - 300 bar. 940692
Relief Valve - Reverse Travel - 300 bar. 940692
Shuttle Valve - Load Sensing. 910629
Relief Valve - Hot Oil Purge. 910630
Shuttle Valve - Hot Oil Purge. 910628
Solenoid Valve - Difflock. 910626
Pilot Operated Diverter Valve - Difflock Front RH. 910625
Pilot Operated Diverter Valve - Difflock Front LH. 910625
Hydraulic Oil Tank. 910912
Flow Divider - Front Axle. 910624
Gear Pump - Steering and Cutterhead Lift. 910695
Front LH Wheel Motor - Pressure Release Disc Brake. 950620
Front RH Wheel Motor - Pressure Release Disc Brake. 950620
Steering Cylinder - Rear Axle. 70-01-195W
Brake Control Valve. 74-06-015W
Gear Pump - Cutterhead Drive. 910695
Check Valve - Transmission Forward Bypass. -
Check Valve - Transmission Reverse Bypass. -
Relief Valve - 110 bar. -
Check Valve - Oil Cooler Bypass - 4 bar. 910641
Oil Cooler. 70-06-171
Return Filter - Bypass Check Valve - 2 bar . 924865
Suction Strainer - No Bypass. 65-06-305
Pressure Filter - No Bypass. 950597
Hydraulic Motor - LH Front Cutterhead. 940602
Diverter Valve - LH Front Cutterhead. 953601
Hydraulic Motor - RH Front Cutterhead. 910696
Diverter Valve - RH Front Cutterhead. 953601
Hydraulic Motor - Centre Cutterhead. 940602
Diverter Valve - Centre Cutterhead. 953601
Rear Porting Manifold. 924687
Solenoid Valve - Forward/Reverse Check Valve 4WD. 924688
Relief Valve - Cutterheads - 250 bar. 910708
Solenoid Valve - Cutterhead Drive. 70-06-245
Restrictor Valve - Variable Weight Assist. 910709
Spool Valve - Cutterhead Lift LH. -
Spool Valve - Cutterhead Lift Centre. -
Spool Valve - Cutterhead Lift RH. -
Hydraulic Cylinder - LH Front Cutterhead. 910109
Hydraulic Cylinder - Centre Cutterhead. 910109
Hydraulic Cylinder - RH Front Cutterhead. 910109
Check Valve - Steering Shock Bypass RH. -
Check Valve - Steering Shock Bypass LH. -
Relief Valve - Steering Shock LH. -
Relief Valve - Steering Shock RH. -
Check Valve / Orifice - Motor Bypass LH Front Cutterhead. -
Check Valve / Orifice - Motor Bypass RH Front Cutterhead. -
Check Valve / Orifice - Motor Bypass Centre Cutterhead. -
Steering Unit. 910649W
Wheel Motor LH Rear. 70-01-018W
1.75
1.75
