MAINTENANCE
1P953C15A
1
2
1.
1. Temperature Switch
2. Hydraulic oil tank
EVERY 500 HOURS Continued.
Check the engine overheat warning system: Turn the ignition key to the ‘ignition on’ position 'I'.
Disconnect the red/grey wire terminal from the engine temperature switch and touch the metal terminal of
this wire onto a suitable earth point, ensuring that the metal surfaces make good contact. The horn will
sound and the engine coolant temperature warning light will illuminate to confirm correct operation. If the
system is faulty, make repairs before operating the mower.
Check the hydraulic oil overheat warning system: Turn the ignition key to the ‘ignition on’ position 'I'.
Disconnect the red/blue wire terminal from the hydraulic tank temperature switch and touch the metal
terminal of the wire onto a suitable earth point, ensuring that the metal surfaces make good contact. The
horn will sound and the hydraulic oil temperature warning light will illuminate to confirm correct
operation. If the system is faulty, make repairs before operating the mower.
1.55
1.55
1
1P953C01A
1. Temperature switch.
