Dimension One Spas - Aquatic Fitness System - Owner’s Manual
6
6. Remove the
filter baskets
and the foam
blocks securing
the filters.
7. Remove one of
the two filters
from the pool side of the system. (If
you have the Dual-Temp model with
separate built-in spa, also remove the
filter from the spa side). (If you need
more details on how to remove the
filters, see the Filter Cleaning section,
pg. 23)
8. Ensure that the hose
bibs are
closed before
filling the spa. The
hose bibs are
connected to hoses in the equipment
compartment. Turn the handles on
the side of the valve perpendicular to
the pipe to close the hose bibs. The
picture at right shows an open hose
bib.
9. Place a garden hose in
the empty filter canister
to fill the system. Fill
the system until the
water level reaches the
center of the tile line.
10. After filling the system, return the filter to its basket. After the filter is in place, turn on the
GFCI circuit breaker. The Display Window of the Pool will show the current water
temperature.
NEVER run your spa’s pumps without the filters in place. This can cause damage to
the pumps.
11. Prime the pumps by pushing the JETS 1 button once and letting it
run for 30 to 45 seconds. To turn off, push it again. Repeat for the
JETS 2 and JETS 3 buttons.
If the jets do not turn on, air is trapped in the plumbing lines. To
eliminate the trapped air, turn the pumps on and off several times to
force the trapped air through the pumps. If the jets still do not turn on,
turn off the pumps and loosen the pump unions slightly to let any
trapped air escape. Re-tighten the pump unions and turn the pumps on
again. Turn the pumps on and off several times until jets function
properly.
