Dimension One Spas - Aquatic Fitness System - Owner’s Manual
5
Initial Startup
Go over the initial startup with your dealer before they begin the installation of your spa.
IMPORTANT: About your GFCI Circuit Breaker — The GFCI (Ground Fault Circuit Interrupter —
also called a "circuit breaker”) automatically shuts off power to the Aquatic Fitness System in case of
an electrical malfunction. You must have a GFCI installed according to your local building codes in
an electrical power box near your system. The GFCI must be OFF before you fill your Aquatic Fitness
System with water. You can manually turn off power to the system any time by moving the switch into
the OFF position. After turning off the GFCI check for a blank control panel screen which means the
power is off. To turn power back on move the switch to the ON position.
If you have questions about the location or operation of your GFCI, ask your dealer for clarification.
DO NOT use your system unless you understand the operation of the GFCI.
1. Locate the equipment
compartment, beneath the steps
of the AFS. Have your dealer
familiarize you with the equipment
components.
2. Use a Phillips screwdriver to
remove the equipment
compartment screws. Open the
compartment.
3. Check the pump unions (see
photo) for hand-tightness and to
prevent the possibility of
leakages.
4. Check near the pumps to make sure
the gate valve has the red safety clips
in place which means that the gate
valve is open (see photo above).
5. Remove the two front and two rear
shipping bolts on each pump mount.
(See photo, left).
