31
To display the individual or interconnect number
currently selected, press and hold the
SHIFT/CLR/MONITOR button and then press the
key.
NOTE
3. Individual - Once the desired individual special call
number is displayed, press and hold the PTT to
initiate the call. The radio performs the necessary
signaling required to obtain a working channel.
Interconnect - Once the desired interconnect special
number is displayed, press and release the PTT to
initiate the call. The radio performs the necessary
signaling required to obtain a working channel.
4. Individual - When the signaling is successfully
completed the BUSY flag turn on and the Call
originate tone sounds. Speak directly into the
microphone. Release the PTT bar as soon as you
stop talking and wait for a reply.
Interconnect - When the signaling is successfully
completed the BUSY flag turns on and the proper
DTMF tones will be sent and heard at the speaker.
When someone answers, press the PTT bar and
speak directly into the microphone. Release the
PTT bar as soon as you stop talking. Messages
cannot be received when the PTT bar is pressed.
