DCA250SSI 3-POSITION WHEEL GEN. • OPERATION AND PARTS MANUAL — REV. #0 (01/13/10) — PAGE 83
ENCLOSURE ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 M5414000002 BASE 1
2 C3414100104 FLOOR PANEL 1
3 M5414100004 FLOOR PANEL 1
4 011008020 HEX HEAD BOLT .......................................12 ...............REPLACES P/N 0017108020
5 M5424000002 FRONT FRAME 1
5A C1494101803 ACOUSTIC SHEET 1
6 031110160 HEX HEAD BOLT 8
7 C1424203403 COVER, FRONT FRAME 1
8 M5424200103 COVER, FRONT FRAME 1
8A C1494200004 ACOUSTIC SHEET 1
9 011008020 HEX HEAD BOLT .......................................23 ...............REPLACES P/N 0017108020
10 0845042703 FILTER BRACKET 1
11 011008020 HEX HEAD BOLT ........................................4 ................REPLACES P/N 0017108020
12 M5434000002 CENTER FRAME 1
12A C1494200004 ACOUSTIC SHEET 1
13 0010114050 HEX HEAD BOLT 4
13A 515455840 HEX NUT .....................................................4 ................REPLACES P/N 0030014000
13B 030214350 WASHER, LOCK .........................................4 ................REPLACES P/N 0040014000
13C 031114260 WASHER, FLAT ..........................................8 ................REPLACES P/N 0041214000
14 0010120045 HEX HEAD BOLT 4
14A 0030020000 HEX NUT 4
14B 030220510 WASHER, LOCK 4
14C 0041220000 WASHER, FLAT 8
15 C2367700404 COVER 1
16 011008020 HEX HEAD BOLT ........................................2 ................REPLACES P/N 0017108020
17 M5444000002 REAR FRAME 1
17A C1494301404 ACOUSTIC SHEET 1
18 031110160 HEX HEAD BOLT 4
19 M5434200003 COVER, REAR FRAME 1
19A C1494301604 ACOUSTIC SHEET 1
20 M5434200104 PANEL 1
20A C1494301504 ACOUSTIC SHEET 1
21 011008020 HEX HEAD BOLT .......................................12 ...............REPLACES P/N 0017108020
22 011008020 HEX HEAD BOLT .......................................14 ...............REPLACES P/N 0017108020
23 M5444200003 DOOR, REAR FRAME 1
24 M5444200103 DOOR, REAR FRAME 1
25 8225147004 WINDOW PLATE 2
