PAGE 12 — DCA250SSI 3-POSITION WHEEL GEN. • OPERATION AND PARTS MANUAL — REV. #0 (01/13/11)
Table 1. Generator Specifi cations
Model
DCA250SSI (3-Position Voltage Selector Switch Wheel)
Type
Revolving fi eld, self ventilated,
open protected type synchronous generator
Armature Connection Star with Neutral Zigzag
Phase
31
Standby Output
220 kW (275 kVA) 158 kW
Prime Output
200 kW (250 kVA) 144 kW
3Ø Voltage (L-L/L-N)
Voltage Selector Switch at 3Ø 240/139
208Y/120, 220Y/127,
240Y/139
N/A
3Ø Voltage (L-L/L-N)
Voltage Selector Switch at 3Ø 480/277
416Y/240, 440Y/254,
480Y/277
N/A
1Ø Voltage (L-L/L-N)
Voltage Selector Switch at 1Ø 240/120
N/A 240/120
Power Factor
0.8 1.0
Frequency
60 Hz
Speed
1800 rpm
Aux. AC Power
Single Phase, 60 Hz
Aux. Voltage/Output
120V/4.8 Kw (2.4 kW x 2)
Sound Level dB (A)
Full Load at 23 ft. (7.0 Meters)
68
Dry Weight
8,203 lbs. (3,720 kg.)/8,303 lbs. (3,766 kg)
Wet Weight
9,305 lbs. (4,220 kg.)/9,360 lbs. (4,245 kg.)
Table 2. Engine Specifi cations
Model
ISUZU BH6UZ1X EPA Tier 3 Certifi ed
Type
4 cycle, water-cooled, direct injection,
turbo-charged air-cooled
No. of Cylinders
6 cylinders
Bore x Stroke
4.72 in. x 5.71 in. (120 mm x 145 mm)
Displacement
600 cu. in. (9,839 cc)
Rated Output
308 HP at 1800 rpm
Starting
Electric 24 VDC
Coolant Capacity
14.3 gal. (54.0 liters)
Lube Oil Capacity
10.8 gal. (41.0 liters)
Fuel Type
#2 Diesel Fuel
Fuel Tank Capacity
121 gal. (458 liters)/ 129 gal. (488 liters)
Fuel Consumption
14.7 gal. (55.8 L)/hr at
full load
10.9 gal. (41.2 L)/hr at
3/4 load
7.5 gal. (28.5 L)/hr at
1/2 load
4.4 gal. (16.6 L)/hr at
1/4 load
Battery
12V-150 Ah x 2/4D (CCA 925 x 2)
SPECIFICATIONS
