DCA250SSI 3-POSITION WHEEL GEN. • OPERATION AND PARTS MANUAL — REV. #0 (01/13/10) — PAGE 81
FUEL TANK ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 C1364002103 FUEL TANK 1
1-1 0605505025 CAP, FUEL TANK 1
1-2 0605505105 FUEL FILTER 1
1-3 0264100525 HOSE, FUEL GAUGE 1
1-4 0605515079 HOSE BAND 2
2 0605503023 FUEL SENSOR 1
3 0802120604 PACKING 1
4 0605501093 UNIT, FUEL 1
5 0605516090 PACKING 1
6 0022905015 MACHINE SCREW 5
7 8195523104 TANK BAND 2
8 0805003414 PAD, TANK BAND 4
9 011008020 HEX HEAD BOLT .......................................2..........REPLACES P/N 0019208020
10 0207308000 SUPER LOCK NUT 2
11 0222100300 TANK SHEET 6
12 0130206000 STREET ELBOW, 1/2" 1
13 0134306200 DRAIN PIPE 1
14 0603325026 VALVE, 1/2" 1
15 0132006000 PLUG, 1/2" 1
16 C1367700304 LOCK PLATE 1
17 011008020 HEX HEAD BOLT .......................................2..........REPLACES P/N 0017108020
18 0845039604 RUBBER SEAL 1
19 M5367700004 BRACKET 1
20 0017110025 HEX HEAD BOLT .......................................2..........REPLACES P/N 0019210025
21 8980758551 PRIMARY FUEL FILTER ASSY .................2..........REPLACES P/N 0602042405
21A 8980758540 ELEMENT, PRIMARY FUEL FILTER .........2..........REPLACES P/N 0602042516
22 8980955010 JOINT PIPE ................................................4..........REPLACES P/N 0602042662
23 1096750951 EYE BOLT ..................................................4..........REPLACES P/N 0602042621
24 1096301110 PACKING ....................................................8..........REPLACES P/N 0602021702
25 0010110080 HEX HEAD BOLT 2
25A 0040010000 WASHER, LOCK 2
25B 031110160 WASHER, FLAT .........................................2..........REPLACES P/N 0041210000
25C 021112140 HEX NUT 2
26 0010110045 HEX HEAD BOLT 4
26A 0040010000 WASHER, LOCK 4
26B 031110160 WASHER, FLAT .........................................4..........REPLACES P/N 0041210000
26C 021112140 HEX NUT 4
27 0130406000 T JOINT, 1/2" 2
28 0130206000 STREET ELBOW, 1/2" 6
29 0602022209 HOSE JOINT 6
30 0131506000 NIPPLE,1/2" 2
31 0191402700 SUCTION HOSE 1
32 0191400700 SUCTION HOSE 4
33 0191400550 SUCTION HOSE 1
34 0191403300 RETURN HOSE 1
35 0605515132 HOSE BAND 14
36 C3366704804 BRACKET 1
37 011008020 HEX HEAD BOLT .......................................2..........REPLACES P/N 0019208020
37A 020108060 HEX NUT 2
