DCA250SSI 3-POSITION WHEEL GEN. • OPERATION AND PARTS MANUAL — REV. #0 (01/13/10) — PAGE 75
OUTPUT TERMINAL ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 C2231700403 SET BOARD, OUTPUT TERMINAL 1
2 C0277500004 OUTPUT TERMINAL 8
3 0801830904 HEX HEAD BOLT 8
3 M9220101004 HEX HEAD BOLT 8
4 0039320000 HEX NUT 16
5 030220510 WASHER, LOCK 24
6 0041420000 WASHER, FLAT 32
7 3501860604 TERMINAL PLATE 3
8 0019210040 HEX HEAD BOLT 5
9 0601808803 CIRCUIT BREAKER, 1P 20A 2
10 0601808804 CIRCUIT BREAKER, 2P 50A 3
11 C3261600704 BRACKET, CIRCUIT BREAKER 1
11-1 0221200150 RUBBER CUSHION 1
12 011206020 HEX HEAD BOLT 2
13 0601814013 RECEPTACLE, GF20LA 2
14 0601811034 RECEPTACLE, CS-6369 3
15 0025304015 MACHINE SCREW 10
15A OEMAA8 HEX NUT 10
16 C2234500104 COVER 1
17 011206020 HEX HEAD BOLT 8
18 0601815324 TERMINAL BOARD 1
19 0025304015 MACHINE SCREW 2
20 0601850275 GROMMET 1
21 0601851780 GROMMET 2
21 0603306775 BLIND PLUG 2
22 C2237102303 COVER, OUTPUT TERMINAL 1
23 012212045 HEX HEAD BOLT 2
24 031112230 WASHER, FLAT 2
25 0805009804 STAY RUBBER 2
26 0030012000 HEX NUT 2
27 M9210000204 SPRING 2
28 C2237101204 COVER 1
28 M5236100204 COVER 1
29 011008020 HEX HEAD BOLT ........................................7 ................REPLACES P/N 0017108020
30 C2237102403 COVER, OUTPUT TERMINAL 1
31 0019210030 HEX HEAD BOLT 2
32 0845054204 COLLAR 2
33 0805009804 STAY RUBBER 1
34 C2237101504 COVER 1
35 C2237400104 BRACKET 1
36 011206020 HEX HEAD BOLT 2
