DCA250SSI 3-POSITION WHEEL GEN. • OPERATION AND PARTS MANUAL — REV. #0 (01/13/10) — PAGE 71
ENGINE AND RADIATOR ASSY. (CONTINUED)
NO. PART NO. PART NAME QTY. REMARKS
20 0605515235 HOSE BAND 1
21 0605515236 HOSE BAND 1
22 0605515238 HOSE BAND 1
23 C0321200004 DRAIN PIPE 1
24 C0321300004 DRAIN PLUG 1
25 C9101000104 JOINT 1
26 0802024004 PACKING 1
27 0802025004 JOINT 1
28 0805008004 PACKING 1
29 0019208025 HEX HEAD BOLT 2
30 0265801000 HOSE 1
31 0602022294 JOINT 1
32 0603325017 VALVE 1
33 0605515074 HOSE BAND 2
34 0802081003C RESERVE TANK 1
34A 0802010900 CAP, RESERVE TANK 1
35 C1317100103 BRACKET, RESERVE TANK 1
36 011008020 HEX HEAD BOLT ........................................2 ................REPLACES P/N 0017108020
36A 020108060 SELF- LOCKING NUT 2
37 0602022929 JOINT 1
38 0199901000 HOSE 1
39 0199900350 HOSE 1
40 0199900650 HOSE 1
41 0193602300 HOSE 1
42 0605515170 HOSE BAND 6
43 0193600550 HOSE 1
44 0193601300 HOSE 1
45 M5324300004 HOSE 1
46 M5324300104 HOSE 1
47 0602022536 ADAPTOR 4
48 0602122272 OIL PRESSURE UNIT 1
48-1 M5324500004 BUSH, 1/8" NPT 1
48-2 0602021182 PACKING 1
49 0602123267 WATER TEMPERATURE UNIT 1
49-1 9095720140 PACKING .....................................................1 ................REPLACES P/N 0602021109
