Model: WS-1517 www.lacrossetechnology.com/support 15
Wind Direction
Wind Direction is set to North during setup. Failure to set the wind direction or mount the wind sensor facing north will
result in incorrect wind direction readings. If your wind direction is incorrect, follow the instructions in step 6 of the “Setup
Instructions Step-by-step” to reset the direction.
With the wind icon flashing, press and release the SET button to change the wind display to view wind direction as letters
(N, S, E, W) or degrees of direction (22.5º). The arrow within the compass rose indicates the direction.
Wind Speed, Wind Gust, Wind Chill
Wind Speed is “sampled” every 11 seconds. The current wind speed viewed on the display is the average wind
speed over the past 10 minutes.
Wind Gust is “sampled” every 11 seconds. These readings are sent to the weather station every 33 seconds as
current wind gust. You may find the wind gust helpful for readings updated more often than the 10 minute average
wind speed.
Wind Chill is a combination of wind speed and the outdoor temperature recorded by the wind sensor. Wind Chill will
only read in Fahrenheit.
Select Wind Speed Unit: km/h, mph, m/s or knots
With the wind icon flashing, hold the SET button to set the wind speed units in:
km/h (kilometers per hour)
mph (miles per hour)
m/s (meters per second)
knots
Wind MAX/MIN
The weather station records the maximum wind speed and wind gusts collected during the day. Alerts for wind speed and
wind gust may be programmed.
View: With the wind icon flashing, press and release the MEMORY button to view:
Current average wind speed
Daily maximum wind speed
Gust speed
Daily maximum gust speed
Reset: With the wind icon flashing, hold the MEMORY button to reset all wind statistics.
Set Wind Alerts
The weather station provides the option to set Wind Speed Hi alert and Wind Gust Hi alert.
To set alerts:
1. With the wind icon flashing, press ALARM/CHART button to select the desired alarm.
2. Hold the ALARM/CHART button until the wind alert and corresponding icon flash.
3. Set the alert using UP or DOWN arrow button.
4. Press and hold either button for fast digits advance.
5. Press ALARM/CHART button to confirm your selection and return to the wind alert selection screen.
Disable the Wind Alert
To disable wind alert when it is displayed, after pressing ALARM/CHART button, press the UP or DOWN arrow button
until the wind alert reads OFF.
Note: The wind speed alert is set at 5 mph default and the wind gust alert is set to 7 mph default to prevent false alerts
from small fluctuations.
