Page 27For technical questions, please call 1-800-444-3353.SKU 67596
When ordering replacement parts from this list, the “A” sufx must be included in order
to get the correct part.
Parts List A - Pump
Part Description
1A Screw M8x16
2A Flange
3A O-Ring 80x2,4
4A Radial Shaft Seal
5A Real Bearing
6A Sheath
7A Wobble Plate
8A Front bearing
9A Spring Disk
10A 15mm Plunger
11A Plunger Spring
12A Crankcase
13A O-Ring 14.2x1.9
14A Brass Pump Plug
15A Oil Seal
16A O-ring 15x2.2
17A Spacer
18A O-ring 22x2
19A Pressure Ring
20A Water seal
21A Inlet valve plug
Part Description
22A Backup ring
23A O-ring
24A Check Valve
26A Detergent Inlet
Connector
27A O-ring 4.47x1.78
28A Ball
29A Cone spring
30A O-ring
31A Outlet Valve
32A Valve spring
33A O-ring
34A Siphon Body
36A Outlet Connector
37A Backup Ring
38A O-ring
39A Valve Core
40A Pump Manifold
41A Seal Gasket
42A Water Inlet Body
43A Thermal Relief Valve
Part Description
44A Pressure Regulator Knob
45A Screw Plug
46A Backup Ring
47A O-ring
48A Spring Holder
49A Large Pressure Spring
50A Small Pressure Spring
51A Ball Holder
53A Ball
52A Valve Port
54A O-ring
55A Manifold Bolt
56A Inlet Swivel Nut
57A Clip Ring
58A Water Filter
59A Pump Breather Plug
60A Dipstick
61A Drain Plug
62A O-ring
