2. SPECIFICATIONS
2.1 MODEL NUMBER:
Serial Nos. 670,000 & Higher: VH15KA362; VH15KA483
2.2 ENGINE
2.2.1 Engine Specifications: See your Engine Owner's Manual.
2.2.2 3600 RPM (No Load).
2.3 FUEL SYSTEM
2.3.1 Capacity: 5.0 gal. (18.9 L.)
2.3.2 Type of Fuel: Regular unleaded gasoline, 87 octane or higher. In countries
using the research method, it should be a 90 octane minimum.
2.3.3 Fuel Filter: Replaceable in-line
2.3.4 Fuel Shut-Off Valve: 1/4 turn
2.4 SAFETY INTERLOCK SYSTEM
Operator must have speed control lever in neutral and PTO disengaged to start engine.
Release of OPC levers will cause the engine to stop if speed control lever is not in
neutral and/or PTO is engaged.
2.5 STEERING/BRAKE CONTROL
Fingertip drive control levers provide independent speed control, braking and neutral to
each drive wheel for moving forward or reverse, stopping and power turning.
2.6 TRANSMISSION
Twin Hydrostatic Drive
2.6.1 Two Hydro Gear variable displacement pumps independently coupled to two
high efficiency Parker/Ross wheel drive motors.
2.6.2 Hydraulic Filter is replaceable cartridge type.
P/N 109-4180: 25 microns, 10 psi bypass (Summer use above 32°
F (0° C))
P/N 1-523541: 40 microns, 18 psi bypass (Winter use below 32°
F (0° C))
2.6.3 Speed Range: Forward 0 - 6.2 mph (10.0 km/h)
Reverse 0 - 2.2 mph (3.5 km/h)
2.7 WHEEL DRIVE SYSTEM
Drive wheels are direct coupled to Parker/Ross wheel drive motors with 1.0" (25.4 mm)
tapered shaft.
2.8 TIRES
Drive Front Caster
36” Deck 48” Decks All decks
Pneumatic (Air-Filled) Pneumatic (Air-Filled)
Semi-Pneumatic
Size 16 x 6.50-8 16 x 7.50-8 9 x 3.50-4
Quantity 2 2 2
Tread Turf Master Turf Master Smooth
Ply Rating 4 4
Pressure 14 psi (97 kPa) 14 psi (97 kPa)
