Maintenance
Figure 19
Located on the back of the seat.
1. Read the instructions
before servicing or
performing maintenance
4. Check oil level.
2. Grease idler pivots. 5. Check hydraulic oil level
and refer to Operator’s
manual for further
instructions.
3. Time interval.
6. Check tire pressure.
4. Connect a grease gun to each tting (Figure 18
and Figure 19). Pump grease into the ttings until
grease begins to ooze out of the bearings.
5. Wipe up any excess grease.
Engine Maintenance
Servicing the Air Cleaner
Service Interval: Before each use or daily
Every 100 hours—Replace
the paper element. (More
often under extremely
dusty, dirty conditions.)
This engine is equipped with a replaceable, high
density paper air cleaner element. Check the air
cleaner daily or before starting the engine. Check for
a buildup of dirt and debris around the air cleaner
system. Keep this area clean. Also check for loose or
damaged components. Replace all bent or damaged
air cleaner components.
Note: Operating the engine with loose or damaged
air cleaner components could allow unltered air into
the engine causing premature wear and failure.
Note: Service the air cleaner more often under
extremely dusty, dirty conditions.
Figure 20
1. Air cleaner 3. Air cleaner cover
2. Knobs
Servicing Paper Element
Service Interval: Every 25 hours (May
need more often under
extremely dusty or dirty
conditions.)
Every 100 hours/Yearly
(whichever comes
rst)—Replace the air
cleaner element.
1. Remove the air cleaner cover (Figure 20).
2. Remove the air cleaner element with the integral
rubber seal.
3. Remove the foam sleeve from the element.
4. Gently tap the pleated side of the paper element
to dislodge dirt. Do Not wash the paper element
or use pressurized air, as this will damage the
element. Replace a dirty, bent, or damaged
element. Handle new elements carefully; Do Not
use if the rubber seal or foam sleeve is damaged.
31
