Operation
release lever back in the released state. Repeat this
on each side of the machine.
5. Release the parking brake. The machine is now
able to be pushed by hand.
To Operate the Machine
Loosen the bypass knob, push the release levers
forward, and retighten the knob to engage the drive
system (Figure 16).
Side Discharge
The mower has a hinged discharge deector that
disperses clippings to the side and down toward the
turf.
DANGER
Without the discharge deector, mulch kit,
or entire grass collection system mounted in
place, you and others are exposed to blade
contact and thrown debris. Contact with
rotating mower blade(s) and thrown debris
will cause injury or death.
• Never remove the discharge deector
from the mower because the discharge
deector routes material down toward
the turf. If the discharge deector is ever
damaged, replace it immediately.
• Never put your hands or feet under the
mower.
• Never try to clear discharge area or
mower blades unless you move the move
the blade control switch to Off and rotate
the ignition key to Off. Also remove the
key and pull the wire off the spark plug(s).
Transporting
Transporting a Unit
Use a heavy-duty trailer or truck to transport the
machine. Lock brake and block wheels. Securely
fasten the machine to the trailer or truck with straps,
chains, cable, or ropes. Be sure that the trailer or truck
has all necessary lighting and marking as required by
law. Secure a trailer with a safety chain.
CAUTION
This unit does not have proper turn
signals, lights, reective markings, or a
slow moving vehicle emblem. Driving on a
street or roadway without such equipment
is dangerous and can lead to accidents
causing personal injury. Driving on a street
or roadway without such equipment may also
be a violation of State laws and the operator
may be subject to trafc tickets and/or nes.
Do Not drive a unit on a public street or
roadway.
WARNING
Loading a unit on a trailer or truck increases
the possibility of backward tip-over.
Backward tip-over could cause serious injury
or death.
• Use extreme caution when operating a
unit on a ramp.
• Use only a single, full width ramp; Do
Not use individual ramps for each side
of the unit.
• If individual ramps must be used, use
enough ramps to create an unbroken
ramp surface wider than the unit.
• Do Not exceed a 15° angle between ramp
and ground or between ramp and trailer
or truck.
• Avoid sudden acceleration while driving
unit up a ramp to avoid tipping backward.
• Avoid sudden deceleration while backing
unit down a ramp to avoid tipping
backward.
Loading a Unit
Use extreme caution when loading units on trailers or
trucks. One full width ramp that is wide enough to
extend beyond the rear tires is recommended instead
of individual ramps for each side of the unit. The
lower rear section of the tractor frame extends back
between the rear wheels and serves as a stop for
tipping backward. Having a full width ramp provides
26
