Maintenance
Important: Refer to your Engine Operator’s Manual for additional maintenance procedures.
Premaintenance
Procedures
Raising the Seat
Make sure the motion control levers are locked in
the neutral position. Lift the seat forward until the
lanyard is tight. The following components can be
accessed by raising the seat:
• Auxiliary 12V Plug (12V accessory up to 15 amp)
• Fuses
• Battery cables
Accessing the Battery
The battery is located under the seat. To access, raise
the seat (Figure 17).
Figure 17
1. Auxiliary 12V Plug
3. Seat
2. Battery
Periodic Maintenance
Lubrication
Greasing the Bearings
Service Interval: Every 25 hours
Grease Type: NGLI grade #2 multi-purpose gun
grease.
Grease the front caster wheels (Figure 18).
1
G007184
Figure 18
1. Front caster tire
1. Park the machine on a level surface and disengage
the blade control switch.
2. Move the motion control levers outward to the
neutral position, engage parking brake, stop the
engine, remove the key, and wait for all moving
parts to stop before leaving the operating position.
3. Clean the grease ttings (Figure 18 and Figure 19)
with a rag. Make sure to scrape any paint off of
the front of the tting(s).
30
