Maintenance
C. Apply lubricant to threads of blade bolt to
prevent seizing. Copper-based anti-seize
preferable. Grease acceptable substitute.
Install blade bolt nger tight. Place wrench
on the top spindle nut then torque the blade
bolts to 50-60 ft-lb (68-81 N-m).
WARNING
Incorrect installation of the blade or
components used to retain the blade can
be dangerous. Failure to use all original
components and assembled as shown could
allow a blade or blade component to be
thrown out from under the deck resulting in
serious personal injury or death.
Always install the original Exmark blades,
blade bushings, and blade bolts as shown.
Check Safety Interlock
System
Service Interval: Before each use or daily
Note: To prevent engine cut-outs on rough terrain
the seat kill switch has a 1/2 second delay.
1. Check starting circuit. Starter should crank with,
parking brake engaged, PTO disengaged and
motion control levers moved out in the neutral
lock position. The operator does not need to be
in the seat to start the engine.
Try to start with operator in seat, parking brake
disengaged, PTO disengaged and motion control
levers in the neutral lock position - starter must
not crank.
Try to start with operator in seat, parking brake
engaged, PTO engaged and motion control
levers in the neutral lock position - starter must
not crank.
Try to start with operator in seat, parking
brake engaged, PTO disengaged, and the left
motion control lever in, starter must not crank,
repeat again with the right lever in, then with
both levers in - starter must not crank.
2. Check the kill circuits. Run engine at one-third
throttle, disengage parking brake and raise off
of seat (but do not get off of machine) engine
must initiate shutdown after approximately 1/2
second has elapsed (seat has time delay kill switch
to prevent cut-outs on rough terrain).
Run engine at one-third throttle, engage PTO
and raise off of seat (but do not get off of
machine) engine must initiate shutdown after
one second has elapsed if the handles are in. The
delay will be 1/2 second if the handles are out.
Run engine at one-third throttle, with brake
disengaged, move levers in and raise off seat (but
do not get off of machine) engine must initiate
shutdown after 1/2 second has elapsed.
Again, run engine at one-third throttle, brake
engaged, and move left motion control lever
in - engine must initiate shutdown after 1/2
second has elapsed.
Repeat again moving the right lever in, then
moving both levers in - engine must initiate
shutdown after 1/2 second has elapsed whether
operator is on seat or not.
Note: If machine does not pass any of these tests,
do not operate. Contact your authorized EXMARK
SERVICE DEALER.
Important: It is essential that operator safety
mechanisms be connected and in proper
operating condition prior to use for mowing.
Check Rollover Protections
Systems (Roll Bar) Knobs
Service Interval: Before each use or daily
Check that both the mounting hardware and the
knobs are in good working condition. Make sure the
knobs are fully engaged with the ROPS in the raised
position. The upper hoop of the roll bar may need
to be pushed forward or pulled rearward to get both
knobs fully engaged.
