Safety Instructions
17
SAFETY, CONTROL, AND INSTRUCTION DECALS
Safety, Control, and Instruction Decals are installed on the machine;
if any are missing, illegible, or damaged, a replacement should be ordered and installed before
putting the machine into operation. The Decal Part Number is listed below and in the Parts Manual.
Location: Front Body, LH Side Above Mufer
Part Number: 8600-12
1. Warning – carbon monoxide (CO) poisoning
hazard.
• CO emitted by a running engine can be deadly.
• Do not operate indoors or in other enclosed
areas.
8600-12
1.
Location: Instrument Panel
Part Number: 8823-6
Location: Front Body Adjacent to RH
Steering Lever
Part Number: 8600-34
1. Warning – read Operator’s Manual before oper-
ating the machine.
Warning – wear eye and ear protection when op-
erating the machine.
2. Warning – roll-over hazard
• Do not operate on slopes greater than 15
degrees.
3. Warning – thrown object hazard.
• Keep bystanders away from the machine
when operating.
4. Warning – entanglement hazard.
• Keep all guards in place while engine is run-
ning.
2.
1.
3.
4.
Location: Gearbox Cover
(Gear Drive Decks Only)
Part Number: 8600-9
1. Tighten blade nuts on gear driven decks to
60 lb·ft (81 N·m).
1.
8600-9
60 lb·ft (81 N·m)
