Specifications
5
MODEL
MDD
DIMENSIONS (Tractor and Mower)*
Length 91 in. (231 cm)
Width 49 in. (124 cm)
Height 44 in. (112 cm)
Wheel Base (Tractor) 42-1/4 in. (107 cm)
Tread Width (Tractor) 29-3/4 in. (76 cm)
MOWER DECK
Width of Cut SD/GHS 42 or 48 in. (107 or 122 cm)
Cutting Height 1 to 4 in. (3 to 10 cm)
Height Adjustment 7 Positions - 1/2 in. (1 cm) Increment Hitch Pins Installed in
Multi-Position Deck Support
Blade Size (Typical)
42 in. (107 cm) SD 22 in. (56 cm)
2 in. (5 cm) Center Overlap
(Two Blades, CW Rotation)
48 in. (122 cm) GHS 25 in. (64 cm)
2 in. (5 cm) Center Overlap
(Two Blades, Counter Rotate)
Deck Suspension Torsion-Flex Frame with Caster Wheels and Counterweight
Springs
CURB WEIGHT (Approximate)
SD Tractor Only 760 lb (345 kg)
GHS Tractor Only 850 lb (386 kg)
Tractor and Mower* 1020 lb (463 kg)
*Dimensions and weight shown are for 48 in. (122 cm) GHS Model (typical).
Dimensions for Tractor and Mower with 42 in. (107 cm) deck are:
Length = 88 in. (224 cm)
Width = 43 in. (110 cm)
For SD Models, subtract 7 in. (18 cm) from the height.
Deck weight for 48 in. (122 cm) Tilt-Up deck = 205 lb (93 kg). Deck sizes range from 42 to 72 in.
(107 to 183 cm), with corresponding deck weights ranging from 170 to 400 lb (77 to 181 kg).
Optional (9.5 Bushel) Grass Catcher adds approx. 5 lb (2 kg) and 5 in. (13 cm) in Height
